Mitsubishi FR-E740-2.2KSC-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E740-2.2KSC-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E740-2.2KSC-60 |
Mitsubishi Variable Frequency Drive FR-E740-2.2KSC-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 325 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 6 |
| Rated Motor Capacity ND (kW) | 2,2 |
| Control Method | V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 3 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 100 |
| Protection Class | IP20 |
| Depth (mm) | 141 |
| Weight (kg) | 1,9 |
| Width (mm) | 140 |
| Height (mm) | 150 |
| Standby Power Consumption (W) | 9,8 |
The Mitsubishi FR-E740-2.2KSC-60 Variable Frequency Drive combines 6A rated current, 2.2kW motor support, and dependable Magnetic Flux Vector Control for industrial automation tasks. The Mitsubishi FR-E740-2.2KSC-60 is part of the FR-E700 SERIES and includes RS-485 Modbus-RTU, USB capability, spring clamp terminals, and a practical 3-digit LED interface for quick status monitoring.
This drive supports conveyors, packaging machines, small process systems, and assembly-line equipment needing consistent torque and stable motor speed regulation. Its vector control response, multiple digital inputs, and flexible analogue output options help ensure smooth integration into PLC-controlled and panel-mounted automation environments.
The Mitsubishi FR-E740-2.2KSC-60 Variable Frequency Drive provides reliable motor operation with 6A capability and 2.2kW performance, making it suitable for continuous-duty industrial applications. Mitsubishi’s FR-E700 SERIES design ensures dependable operation, robust communication through Modbus-RTU, and IP20 protection, supporting long-term use in factory automation setups.
