Mitsubishi FR-E740-060SC-ENE Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E740-060SC-ENE:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E740-060SC-ENE |
Mitsubishi Variable Frequency Drive FR-E740-060SC-ENE Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700-ENE INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 325 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 6 |
| Rated Motor Capacity ND (kW) | 2,2 |
| Control Method | V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 3 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Ethernet Port | 1 |
| Built-In Network | MODBUS/TCP, CC-Link IE Field Network Basic |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 100 |
| Protection Class | IP20 |
| Depth (mm) | 141,5 |
| Weight (kg) | 1,9 |
| Width (mm) | 140 |
| Height (mm) | 150 |
| Standby Power Consumption (W) | 9,8 |
Get A Quote for Variable Frequency Drive FR-E740-060SC-ENE at the best price. Here are the brief Technical Specifications of FR-E740-060SC-ENE are FR-E700-ENE INVERTER from the FR-E700 SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 325V, a maximum rated voltage of 480V, and a maximum permissible voltage of 528V. It is designed with an IP20 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 141,5 mm, a width of 140 mm, and a height of 150 mm, making it suitable for space-constrained installations. It weighs 1,9 kg, ensuring easy handling and installation. It's Time to get a Quote for your requirement of Variable Frequency Drive. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
