Mitsubishi FR-E720S-050SC-ENE Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720S-050SC-ENE:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720S-050SC-ENE |
Mitsubishi Variable Frequency Drive FR-E720S-050SC-ENE Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700-ENE INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 1 |
| Rated Output Current ND (A) | 5 |
| Rated Motor Capacity ND (kW) | 0,75 |
| Control Method | V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 3 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Ethernet Port | 1 |
| Built-In Network | MODBUS/TCP, CC-Link IE Field Network Basic |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 50 |
| Protection Class | IP20 |
| Depth (mm) | 163 |
| Weight (kg) | 1 |
| Width (mm) | 108 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 5,8 |
Mail Us for your needs in Variable Frequency Drive FR-E720S-050SC-ENE with budget-friendly prices. The Main Technical Parameters of FR-E720S-050SC-ENE include FR-E700-ENE INVERTER from the FR-E700 SERIES at competitive prices. This AC inverter operates on 1-phase power with a minimum rated voltage of 200V, a minimum permissible voltage of 170V, a maximum rated voltage of 240V, and a maximum permissible voltage of 264V. It is designed with an IP20 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 163 mm, a width of 108 mm, and a height of 128 mm, making it suitable for space-constrained installations. It weighs 1 kg, ensuring easy handling and installation. Customize Your Experience with a Quote for your requirement off Variable Frequency Drive. Experience the difference with our competitive pricing and superior support over other Suppliers.
