Mitsubishi Variable Frequency Drive FR-E720S-015SC-ENE Technical Specifications:
Specification
Value
Series
FR-E700 SERIES
Type
FR-E700-ENE INVERTER
Minimum Rated Voltage (V)
200
Min. Permissible Voltage (V)
170
Maximum Rated Voltage (V)
240
Max. Permissible Voltage (V)
264
Current Type
AC
Phases
1
Rated Output Current ND (A)
1,5
Rated Motor Capacity ND (kW)
0,2
Control Method
V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type
INDUCTION MOTOR
Brake Chopper ED (%)
30
Integrated EMC Filter
NO
Safe Torque Off (STO)
YES
Regenerative (4Q)
NO
Integrated DC Choke
NO
Display
BUILT-IN
Display Type
3 DIGITS LED
PLC Function
NO
Integrated Digital Inputs
6
Digital Outputs (Transistor)
2
Digital Outputs (Relay)
1
Integrated Analogue Inputs
2
Integrated Analogue Outputs
1
IO Type of Terminal Block
SPRING CLAMP
Expandable
YES
RS-485
1
USB
1
Ethernet Port
1
Built-In Network
MODBUS/TCP, CC-Link IE Field Network Basic
Leakage Current (mA)
1
Power Loss ND (W)
20
Protection Class
IP20
Depth (mm)
108
Weight (kg)
0,5
Width (mm)
68
Height (mm)
128
Standby Power Consumption (W)
4,5
Send Your Inquiry for Variable Frequency Drive FR-E720S-015SC-ENE with cost-effective solutions. Essential Technical Specs of FR-E720S-015SC-ENE are FR-E700-ENE INVERTER from the FR-E700 SERIES at competitive prices. This AC inverter operates on 1-phase power with a minimum rated voltage of 200V, a minimum permissible voltage of 170V, a maximum rated voltage of 240V, and a maximum permissible voltage of 264V. It is designed with an IP20 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 108 mm, a width of 68 mm, and a height of 128 mm, making it suitable for space-constrained installations. It weighs 0,5 kg, ensuring easy handling and installation. Capture the Best Deal with a Quote for your requirement of Variable Frequency Drive. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
