Mitsubishi FR-E720-008-NA Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720-008-NA:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720-008-NA |
Mitsubishi Variable Frequency Drive FR-E720-008-NA Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 0,8 |
| Rated Motor Capacity ND (kW) | 0,1 |
| Control Method | MAGNETIC FLUX VECTOR CONTROL, V/F CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SCREW |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 14 |
| Protection Class | IP20 |
| Depth (mm) | 81 |
| Weight (kg) | 0,5 |
| Width (mm) | 68 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 4,5 |
The Mitsubishi FR-E720-008-NA Variable Frequency Drive offers efficient motor control with a 0.8A output rating, 0.1kW motor capacity, and a 200β240V operating range. As a member of the FR-E700 SERIES, it provides magnetic flux vector control, a built-in LED interface, and MODBUS-RTU communication through RS-485, making it suitable for compact automation applications across industrial environments.
The Mitsubishi FR-E720-008-NA Variable Frequency Drive is suited for conveyors, feeders, packaging systems, and other light automation tasks that require stable and precise motor operation. Its consistent torque delivery, reliable speed management, and compact form factor allow easy integration into control panels. Screw-type terminals and low power requirements make it practical for OEM machines and small industrial setups.
The Mitsubishi FR-E720-008-NA Variable Frequency Drive ensures dependable performance with its 0.8A rated output, 0.1kW capacity, and MODBUS-RTU network support. Mitsubishiβs engineering quality and the FR-E700 SERIES design principles make it a trustworthy option for industrial users needing compact, efficient, and stable motor control. It fits well in applications where smooth operation and long-term reliability are essential.
