Mitsubishi FR-E720-0.4KSC Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720-0.4KSC:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720-0.4KSC |
Mitsubishi Variable Frequency Drive FR-E720-0.4KSC Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 3 |
| Rated Motor Capacity ND (kW) | 0,4 |
| Control Method | V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 32 |
| Protection Class | IP20 |
| Depth (mm) | 118,5 |
| Weight (kg) | 0,7 |
| Width (mm) | 68 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 4,5 |
The Mitsubishi FR-E720-0.4KSC Variable Frequency Drive provides stable motor control with a 3A rated output, a 0.4kW motor capacity, and a 200β240V AC operating range. Supporting V/F and magnetic flux vector control, it ensures predictable torque and speed regulation. As part of the FR-E700 SERIES, this model is commonly used in light industrial automation applications that require dependable control of small induction motors.
The Mitsubishi FR-E720-0.4KSC Variable Frequency Drive suits conveyors, compact packaging machines, feeders, and small assembly systems. Vector control supports smoother low-speed performance, while RS-485 and MODBUS-RTU allow integration into industrial panels. With STO functionality, LED status indication, and reliable IP20 protection, it performs consistently in environments where compact drives must operate continuously with minimal supervision.
The Mitsubishi FR-E720-0.4KSC Variable Frequency Drive ensures dependable operation with its 3A output, clear control modes, and robust 200β240V input handling. Mitsubishiβs engineering delivers reliable speed management for small automation systems that require safe and predictable motor performance. With RS-485 connectivity, STO, and structured I/O, this model supports long-term industrial use while maintaining stable and efficient functionality.
