Mitsubishi FR-E720-0.1KSC Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720-0.1KSC:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720-0.1KSC |
Mitsubishi Variable Frequency Drive FR-E720-0.1KSC Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 0,8 |
| Rated Motor Capacity ND (kW) | 0,1 |
| Control Method | V/F CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 14 |
| Protection Class | IP20 |
| Depth (mm) | 86,5 |
| Weight (kg) | 0,5 |
| Width (mm) | 68 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 4,5 |
The Mitsubishi FR-E720-0.1KSC Variable Frequency Drive provides dependable motor control for small-capacity loads with a 0.1kW rating, 0.8A output, and a 200β240V input range. As part of the FR-E700 SERIES, it supports V/F and magnetic flux vector control, includes a built-in LED display, and offers RS-485 MODBUS-RTU communication for integration in industrial automation systems.
The Mitsubishi FR-E720-0.1KSC Variable Frequency Drive is suitable for conveyors, light packaging equipment, compact automation units, and basic motion applications. Its stable control characteristics, efficient torque handling, and reliable startup behavior make it useful for operations requiring precise low-power motor performance. Spring-clamp terminals ensure secure wiring in environments with continuous vibrations or frequent maintenance.
The Mitsubishi FR-E720-0.1KSC Variable Frequency Drive delivers consistent performance using its 0.8A output capability, 200β240V input range, and MODBUS-RTU connectivity. Mitsubishi maintains strong reliability, ensuring compatibility with small industrial machines and auxiliary automation systems. This drive fits well in facilities seeking simple installation, steady operation, and dependable motor control for low-capacity applications.
