Mitsubishi FR-E720-0.1K Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720-0.1K:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720-0.1K |
Mitsubishi Variable Frequency Drive FR-E720-0.1K Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 0,8 |
| Rated Motor Capacity ND (kW) | 0,1 |
| Control Method | MAGNETIC FLUX VECTOR CONTROL, V/F CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SCREW |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 14 |
| Protection Class | IP20 |
| Depth (mm) | 80,5 |
| Weight (kg) | 0,5 |
| Width (mm) | 68 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 4,5 |
The Mitsubishi FR-E720-0.1K Variable Frequency Drive offers reliable motor control with a 0.8A rating, a 0.1kW motor capacity, and a 200β240V operating range. Its magnetic flux vector control and V/F control ensure predictable speed and torque for small induction motors. As part of the FR-E700 SERIES, this model is suited for compact automation systems requiring stable and efficient motor operation.
The Mitsubishi FR-E720-0.1K Variable Frequency Drive is suitable for miniature conveyors, feeders, compact packaging mechanisms, and light-duty assembly equipment. Its vector control supports smooth low-speed performance, while RS-485 and MODBUS-RTU enable integration with factory automation panels. STO enhances safety, and the LED display provides clear operational visibility in continuous-duty use.
The Mitsubishi FR-E720-0.1K Variable Frequency Drive provides consistent performance through its 0.8A output, stable control modes, and dependable 200β240V handling. Mitsubishi engineering ensures reliable speed regulation and functional durability for small-scale industrial applications. With RS-485 communication, USB access, structured inputs and outputs, and IP20 protection, it remains a trusted choice for precise and efficient motor control.
