Mitsubishi FR-D710W-0.4K Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-D710W-0.4K:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-D710W-0.4K |
Mitsubishi Variable Frequency Drive FR-D710W-0.4K Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-D700 SERIES |
| Type | FR-D700 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 100 |
| Min. Permissible Voltage (V) | 90 |
| Maximum Rated Voltage (V) | 115 |
| Max. Permissible Voltage (V) | 132 |
| Current Type | AC |
| Phases | 1 |
| Rated Output Current ND (A) | 2,5 |
| Rated Motor Capacity ND (kW) | 0,4 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | NO |
| RS-485 | 1 |
| USB | NO |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 32 |
| Protection Class | IP20 |
| Depth (mm) | 142,5 |
| Weight (kg) | 0,9 |
| Width (mm) | 68 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 5,5-10,5 |
The Mitsubishi FR-D710W-0.4K Variable Frequency Drive features 0.4kW capacity, 2.5A output rating, vector-based control, and STO safety. The Mitsubishi FR-D710W-0.4K belongs to the FR-D700 SERIES and is used in small industrial automation tasks where precise speed control, smooth torque handling, and compact installation are required.
This drive is suitable for conveyors, light-duty packaging machines, feeders, compact processing equipment, and general automation components. Its stable control modes, MODBUS-RTU communication, reliable I/O structure, and efficient thermal profile ensure consistent operation and performance in continuous-duty setups.
The Mitsubishi FR-D710W-0.4K Variable Frequency Drive provides 0.4kW output, vector control, STO protection, and RS-485 connectivity, delivering dependable speed regulation for small motors. Supported by Mitsubishi’s FR-D700 SERIES, this model offers proven reliability and is suitable for users seeking steady, long-term performance in compact industrial environments.
