Mitsubishi FR-AF840-06830-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-AF840-06830-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-AF840-06830-60 |
Mitsubishi Variable Frequency Drive FR-AF840-06830-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-A/F800 SERIES |
| Type | BASE UNIT FOR INV A840/F840 |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 547 |
| Rated Motor Capacity ND (kW) | 280 |
| Control Method | VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | 2 |
| USB | 2 |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Power Loss ND (W) | 5900 |
| Protection Class | IP00 |
| Depth (mm) | 380 |
| Weight (kg) | 166 |
| Width (mm) | 680 |
| Height (mm) | 1010 |
| Standby Power Consumption (W) | 125 |
| Power Loss LD (W) | 6600 |
| Power Loss SLD (W) | 7550 |
| Rated Motor Capacity HD (kW) | 250 |
| Power Loss HD (W) | 5050 |
Give Us a Call for Variable Frequency Drive FR-AF840-06830-60 at the lowest pricing. In-depth Technical Analysis of FR-AF840-06830-60 feature BASE UNIT FOR INV A840/F840 from the FR-A/F800 SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 323V, a maximum rated voltage of 500V, and a maximum permissible voltage of 550V. It is designed with an IP00 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 380 mm, a width of 680 mm, and a height of 1010 mm, making it suitable for space-constrained installations. It weighs 166 kg, ensuring easy handling and installation. Elevate Your Project with a Quote for your requirement of Variable Frequency Drive. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
