Mitsubishi FR-A840-00380-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-A840-00380-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-A840-00380-E2-60 |
Mitsubishi Variable Frequency Drive FR-A840-00380-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-A SERIES |
| Type | FR-A800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 31 |
| Rated Motor Capacity ND (kW) | 15 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | OPTIONAL |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK, MODBUS/TCP, CC-LINK IE FIELD NETWORK BASIC |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Power Loss ND (W) | 390 |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 8,3 |
| Width (mm) | 220 |
| Height (mm) | 300 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 35 |
| Rated Motor Capacity LD (kW) | 18,5 |
| Power Loss LD (W) | 415 |
| Rated Output Current SLD (A) | 38 |
| Rated Motor Capacity SLD (kW) | 18,5 |
| Power Loss SLD (W) | 450 |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| Rated Output Current HD (A) | 23 |
| Rated Motor Capacity HD (kW) | 11 |
| Power Loss HD (W) | 285 |
The Mitsubishi FR-A840-00380-E2-60 Variable Frequency Drive is engineered for precise motor regulation in industrial automation environments. This Mitsubishi model supports 15 kW output, delivers 31 A rated current and operates on a 380β500 V AC three-phase supply. As part of the FR-A SERIES, it offers multiple vector control modes for induction and PM motors while maintaining stable performance across diverse industrial loads.
The Mitsubishi FR-A840-00380-E2-60 Variable Frequency Drive is widely used in conveyors, packaging machines, assembly systems and general-purpose automation. Its LED display, extensive digital inputs, communication capability and reliable torque response support consistent operation. Ethernet connectivity and CC-Link IE networking enhance compatibility with modern automation equipment and control panels.
The Mitsubishi FR-A840-00380-E2-60 Variable Frequency Drive delivers dependable industrial performance with vector control, IP20 protection and efficient three-phase operation. As part of the Mitsubishi FR-A SERIES, it provides trusted motor control for demanding automation applications. Engineers rely on this model for smooth operation, long-term reliability and seamless integration into industrial systems.
