Mitsubishi FR-A840-00038-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-A840-00038-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-A840-00038-E2-60 |
Mitsubishi Variable Frequency Drive FR-A840-00038-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-A SERIES |
| Type | FR-A800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 2,5 |
| Rated Motor Capacity ND (kW) | 0,75 |
| Frequency Range (Hz) | 0,2–590 |
| Control Method | VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | OPTIONAL |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK, MODBUS/TCP, CC-LINK IE FIELD NETWORK BASIC |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Power Loss ND (W) | 55 |
| Protection Class | IP20 |
| Depth (mm) | 140 |
| Weight (kg) | 2,8 |
| Width (mm) | 150 |
| Height (mm) | 260 |
| Standby Power Consumption (W) | 19 |
| Rated Output Current LD (A) | 3,5 |
| Rated Motor Capacity LD (kW) | 1,5 |
| Power Loss LD (W) | 70 |
| Rated Output Current SLD (A) | 3,8 |
| Rated Motor Capacity SLD (kW) | 1,5 |
| Power Loss SLD (W) | 75 |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| Rated Output Current HD (A) | 1,5 |
| Rated Motor Capacity HD (kW) | 0,4 |
| Power Loss HD (W) | 40 |
The Mitsubishi FR-A840-00038-E2-60 Variable Frequency Drive is designed for precise and stable motor control in industrial automation. This Mitsubishi model supports 0.75 kW motor capacity, delivers 2.5 A output current and operates on a 380–500 V AC three-phase supply. As part of the FR-A SERIES, it includes multiple vector control modes suitable for induction and PM motors in varied automation environments.
The Mitsubishi FR-A840-00038-E2-60 Variable Frequency Drive is commonly used in conveyors, compact machinery, assembly systems and small automation setups. Its LED display, digital inputs, relay outputs and Ethernet connectivity support consistent and predictable motor performance. The IP20 housing and spring-clamp terminals make installation efficient and reliable for control panel integration.
The Mitsubishi FR-A840-00038-E2-60 Variable Frequency Drive provides dependable operation through vector control, IP20 design and stable three-phase performance. As a member of the Mitsubishi FR-A SERIES, it delivers trustworthy motor regulation for industrial equipment. Engineers rely on this model for long-term stability, smooth torque control and seamless integration into automation systems.
