Mitsubishi FFR-DT-1500A-SS1 - VFD Inverter
Mitsubishi FFR-DT-1500A-SS1 VFD Inverter
| Brand | Mitsubishi |
| Product Type | VFD Inverter |
| Model Number | FFR-DT-1500A-SS1 |
Mitsubishi FFR-DT-1500A-SS1 VFD Inverter - Technical Specifications:
| Specification | Value |
|---|---|
| Type | DU/DT FILTER |
| Series | ALL |
| Rated Current (A) (fa_ger_79) | 1500 |
| Power Loss (W) | 1100 |
| Protection Class | IP00 |
| Depth (mm) | 250 |
| Weight (kg) | 97 |
| Width (mm) | 360 |
| Height (mm) | 485 |
| Rated Capacity (kW) | 200V: -, 230V: -, 400V: 800 |
