Mitsubishi AJ65SBTC1-32T1 - Programmable Logic Controller
The Mitsubishi AJ65SBTC1-32T1 Programmable Logic Controller (PLC) is a high-speed digital output module designed for distributed control systems. Developed by Mitsubishi, it ensures precise signal transmission and enhanced automation efficiency in compact industrial setups.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | AJ65SBTC1-32T1 |
Technical Specifications of Mitsubishi Programmable Logic Controller AJ65SBTC1-32T1
| Specification | Value |
|---|---|
| Series | CC-LINK |
| Type | REMOTE TRANSISTOR OUTPUT |
| Depth (mm) | 40 |
| Weight (kg) | 0,16 |
| Width (mm) | 118 |
| Height (mm) | 50 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 32 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Rated Load Voltage (VDC) | 12/24 |
| Wiring | SCREW |
| Int. Current Consumption (A) | 0,06 |
| Occupied Stations | 1 |
The Mitsubishi AJ65SBTC1-32T1 PLC is part of the CC-Link series, designed to deliver high-speed and stable digital output performance with 32 transistor outputs using sink logic. It operates at a rated load voltage of 12/24V DC, suitable for actuators, relays, solenoids, and LED indicators in automated systems. The module supports a nominal output current of 2.4 A and can drive devices up to 0.37 kW (0.55 hp), making it ideal for mid-range power switching tasks.
Its dimensionsβ118 mm width, 50 mm height, and 40 mm depthβallow seamless panel integration, while the lightweight build of 0.16 kg simplifies mounting. Built to last, the unit supports an ambient temperature range of -10Β°C to 60Β°C in operation and up to 70Β°C in storage. With compliance to IEC 60068-2-6, it withstands vibration and can be mounted vertically within a Β±10Β° angle, supporting installation in mobile equipment or tight control cabinets.
The AJ65SBTC1-32T1 features an RJ45 Ethernet port and a 2-wire RS-485 interface, allowing seamless data communication with master PLCs and CC-Link-compatible devices. It supports switching frequencies from 2 kHz to 16 kHz, with a standard frequency of 4 kHz for optimal performance tuning. The device operates on 200β240V AC Β±10% at 50/60 Hz, includes IP20 protection, and supports installation at altitudes up to 2000 m (with derating above 1000 m). With only 27 W of power dissipation, it contributes to energy efficiency across industrial control systems.
The Mitsubishi AJ65SBTC1-32T1 is ideal for high-speed switching tasks in automated packaging systems, sorting machines, pick-and-place robotics, and distributed I/O panels. Its 32 transistor outputs make it well-suited for controlling large numbers of actuators, solenoids, and signal lamps with rapid on/off cycles.
For Indian junior engineers and students, this module offers a clear, low-voltage 12/24V DC interface and simple screw terminal wiring, which makes it easy to learn and implement. For senior control engineers, the vibration-resistant construction and compact size make it a practical choice for dynamic environments like moving machinery or mobile units. It fits naturally into CC-Link networks, allowing integration with HMIs, sensors, and main PLC controllers.
If your automation system requires fast, synchronized digital outputs and energy-efficient operation, the Mitsubishi AJ65SBTC1-32T1 PLC offers the right mix of flexibility, speed, and reliability for modern control architectures.
