Mitsubishi AJ65SBTB32-16DR - Programmable Logic Controller
The Mitsubishi AJ65SBTB32-16DR Programmable Logic Controller (PLC) is a versatile I/O module engineered for distributed automation. Designed by Mitsubishi, this unit ensures high-speed signal processing and dependable control in industrial systems.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | AJ65SBTB32-16DR |
Technical Specifications of Mitsubishi Programmable Logic Controller AJ65SBTB32-16DR
| Specification | Value |
|---|---|
| Series | CC-LINK |
| Type | REMOTE I/O COMBINED MODULE |
| Integrated Digital Inputs | 8 |
| Depth (mm) | 40 |
| Weight (kg) | 0,28 |
| Width (mm) | 179 |
| Height (mm) | 50 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 8 |
| Output Type | RELAY |
| Rated Load Voltage (VDC) | 24 |
| Wiring | SCREW |
| Int. Current Consumption (A) | 85 |
| Rated Input Voltage (VDC) | 24 |
| Rated Load Voltage (VAC) | 240 |
| Occupied Stations | 1 |
The Mitsubishi AJ65SBTB32-16DR is a versatile Remote I/O Combined Module in the CC-Link series, featuring 8 digital inputs and 8 relay outputs for flexible machine control. Designed to streamline distributed automation, it supports a 24V DC input and operates with 24V DC and 240V AC load voltages, allowing compatibility with both DC and AC output devices. With a current consumption of 85 mA and 27W power dissipation, it offers energy-efficient performance for control panels with multiple modules.
Measuring 179 mm wide, 50 mm high, and 40 mm deep, this compact module weighs only 0.28 kg and is built for cabinet mounting. Its screw terminal wiring ensures secure connections in high-vibration zones. Compliant with IEC 60068-2-6, the unit supports vertical mounting up to Β±10Β°, ensuring operational stability even in mobile or vibration-prone systems. It also supports altitudes up to 2000 meters with derating, making it suitable for installations in varied geographies and plant elevations.
Equipped with a 2-wire RS-485 interface and an RJ45 Ethernet port, the AJ65SBTB32-16DR PLC ensures reliable data exchange across distributed networks. Its operating range of -10Β°C to 60Β°C and storage tolerance from -25Β°C to 70Β°C enables deployment in harsh industrial conditions. With IP20 protection and 1-station network occupancy, it offers secure, efficient integration without consuming excessive CC-Link bandwidth. Trusted for its high uptime, signal integrity, and cost-effective scaling, this Mitsubishi PLC supports long-term reliability in diverse automation systems.
The Mitsubishi AJ65SBTB32-16DR PLC is widely used in distributed I/O applications across factories and plants where centralized control is not feasible. It is ideal for use in packaging lines, machine tools, conveyors, bottling units, and modular assembly systems. This PLC acts as a local interface that collects input signals from sensors and switches, then sends output signals to relays, contactors, and actuatorsβstreamlining operations and reducing wiring overhead.
For Indian maintenance engineers, this PLC is easy to install using screw terminals, and the relay output ensures compatibility with standard contactors used in local electrical panels. Students and junior engineers learning automation can understand its modular function as a βremote brainβ that talks to the main controller over the CC-Link network, helping the whole machine operate in sync. Senior engineers benefit from its flexible input/output combination and communication stability.
This Mitsubishi PLC is trusted in dusty, hot, and power-variable environments common in Indian manufacturing. Whether retrofitting old machines or building new control cabinets, the AJ65SBTB32-16DR helps you achieve modular, scalable, and efficient automation. Itβs not just a PLCβitβs a practical upgrade for smart factories.
