Mitsubishi AJ65SBTB1-32DT1 - Programmable Logic Controller
The Mitsubishi AJ65SBTB1-32DT1 Programmable Logic Controller (PLC) is a compact, high-performance I/O module developed by Mitsubishi for demanding industrial automation systems requiring fast, reliable data processing and seamless control integration.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | AJ65SBTB1-32DT1 |
Technical Specifications of Mitsubishi Programmable Logic Controller AJ65SBTB1-32DT1
| Specification | Value |
|---|---|
| Series | CC-LINK |
| Type | REMOTE I/O COMBINED MODULE |
| Integrated Digital Inputs | 16 |
| Depth (mm) | 40 |
| Weight (kg) | 0,25 |
| Width (mm) | 179 |
| Height (mm) | 50 |
| Power Supply (V) | 24 |
| Current Type | DC |
| Integrated Digital Outputs | 16 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Rated Load Voltage (VDC) | 24 |
| Wiring | SCREW |
| Int. Current Consumption (A) | 0,06 |
| Rated Input Voltage (VDC) | 24 |
| Occupied Stations | 1 |
Engineered for performance and scalability, the Mitsubishi AJ65SBTB1-32DT1 PLC integrates 16 digital inputs and 16 transistor outputs in a single compact module. With a 24V DC power supply, it supports a rated load voltage of 24 VDC and uses sink-type logic for efficient signal control. Communication is handled via a 2-wire RS 485 physical layer with an RJ45 connector, enabling smooth integration into CC-Link networks. The module operates with an internal current consumption of just 0.06 A, and allows a switching frequency range of 2 kHz to 16 kHz, offering flexibility for time-critical applications.
Physically, the unit measures 179 mm wide, 50 mm high, and 40 mm deep, and weighs only 0.25 kg, making it suitable for compact control panels and distributed I/O systems. The Mitsubishi AJ65SBTB1-32DT1 PLC is designed for industrial reliability, offering a wide operational temperature range of -10 Β°C to 40 Β°C (up to 60 Β°C with a derating factor of 2.2% per Β°C). Its IP20-rated housing and IEC 60068-2-6 compliant vibration resistance ensure dependable operation in harsh environments. Cabinet-mountable and screw-terminal wired, this module fits well in both new automation builds and retrofit projects.
Supported by a supply voltage range of 200 to 240 V AC (Β±15%), and operating at 50/60 Hz, the module offers electrical compatibility across industrial setups. Its proven reliability, minimal footprint, and fast response times make it a trusted solution for PLC-based control applications in automotive, food processing, textile, and packaging industries.
The Mitsubishi AJ65SBTB1-32DT1 PLC is widely used in distributed automation environments, where precise and fast signal transmission is required across multiple zones. Common applications include conveyor systems, robotic arms, pick-and-place machines, packaging lines, and smart manufacturing cells where consistent performance under continuous operation is vital.
Because it integrates both input and output channels, this PLC is ideal for mid-sized machinery where local I/O control is needed, but space and wiring costs must be minimized. Engineers value the flexibility of its transistor outputs for high-speed switching and its compact footprint for mounting within tight enclosures. Its robust performance in dusty, vibrating, and thermally active conditions makes it suitable for long-term deployment in industrial control panels.
For students and junior engineers, this module is an excellent learning platform for real-world control logic, I/O mapping, and fieldbus communication using CC-Link. Its simplified wiring via screw terminals and diagnostic LED indicators aid in fast troubleshooting during lab training or live machine commissioning. Whether you're automating a single machine or expanding a distributed control network, the Mitsubishi AJ65SBTB1-32DT1 PLC provides the reliability, flexibility, and performance your project demands.
