FX5UC-64MT/DSS - Mitsubishi Programmable Controllers Melsec
Mitsubishi FX5UC-64MT/DSS PLC uses 24V DC power, offers 64K steps memory, and delivers transistor outputs for industrial automation control. This controller from Mitsubishi under the Mitsubishi PLC category belongs to the FX Series, supporting 32 digital inputs, 32 digital outputs, 256 local I/O points, Ethernet and RS-485 communication, and expandable system architecture.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX5UC-64MT/DSS |
FX5UC-64MT/DSS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX5UC |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 64K STEPS |
| Program Memory Unit | FLASH |
| Integrated Digital Inputs | 32 |
| Integrated Digital Outputs | 32 |
| Output Type | TRANSISTOR |
| Output Logic | SOURCE |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 512 |
| Expandable | YES |
| Cycle Time LD (ns) | 34 |
| Cycle Time MOV (ns) | 34 |
| Ethernet Port | 1 |
| RS-485 | 1 |
| Power Consumption (W) | 8 |
| Buffer Battery | OPTION |
| Protection Class | IP10 |
| Max. Ambient Temperature (°C) | 55 |
| Series | MELSEC IQ-F SERIES |
| Depth (mm) | 89,1 |
| Weight (kg) | 0,3 |
| Width (mm) | 62,2 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,KR,LR,NK,RINA |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX5UC-64MT/DSS PLC is a programmable logic controller designed for compact and high-speed industrial automation systems. It operates on 24V DC power and provides 64K steps program memory stored in flash for stable control execution. The Mitsubishi FX5UC-64MT/DSS PLC uses transistor outputs and supports 256 local I/O points. It belongs to the FX Series within Mitsubishi’s MELSEC IQ-F controller family.
In industrial applications, the Mitsubishi FX5UC-64MT/DSS PLC is used in conveyors, packaging machines, assembly stations, and modular automation lines. Fast execution times support precise signal handling, while Ethernet and RS-485 interfaces simplify device communication. Expandable I/O capacity allows system scaling without replacing the core PLC, supporting flexible automation layouts.
The Mitsubishi FX5UC-64MT/DSS PLC represents Mitsubishi’s focus on reliable and efficient PLC platforms for continuous operation. Certified compliance, defined electrical characteristics, and low power consumption support long-term industrial use. The FX5UC-64MT/DSS model is suitable for applications requiring compact design, high processing speed, and dependable automation control hardware.
