FX5U-32MT/ES - Mitsubishi Programmable Controllers Melsec
Mitsubishi FX5U-32MT/ES PLC operates on 100β240V AC, provides 64K steps memory, sixteen inputs, sixteen transistor outputs for industrial automation. Manufactured by Mitsubishi, this Mitsubishi PLC belongs to the FX Series and supports FLASH program memory, 256 local I/O points, expandable architecture, SINK transistor output logic, 34 ns LD cycle time, Ethernet and RS-485 communication, and operation up to 55Β°C.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX5U-32MT/ES |
FX5U-32MT/ES Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX5U |
| Power Supply (V) | 100-240 |
| Current Type | AC |
| Program Memory | 64K STEPS |
| Program Memory Unit | FLASH |
| Integrated Digital Inputs | 16 |
| Integrated Digital Outputs | 16 |
| Integrated Analogue Inputs | 2 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 512 |
| Expandable | YES |
| Cycle Time LD (ns) | 34 |
| Cycle Time MOV (ns) | 34 |
| Ethernet Port | 1 |
| RS-485 | 1 |
| Power Consumption (W) | 30 |
| Buffer Battery | OPTION |
| Protection Class | IP10 |
| Max. Ambient Temperature (Β°C) | 55 |
| Series | MELSEC IQ-F SERIES |
| Depth (mm) | 83 |
| Weight (kg) | 0,65 |
| Width (mm) | 150 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,KR,LR,NK,RINA |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX5U-32MT/ES PLC is a programmable logic controller designed for industrial automation control systems. This Mitsubishi FX5U-32MT/ES PLC operates on 100β240V AC power and provides 64K steps program memory stored in FLASH for stable logic execution. It integrates sixteen digital inputs, sixteen transistor outputs, and two analogue inputs, supporting up to 256 local I/O points. The controller is part of the Mitsubishi FX Series within the MELSEC iQ-F platform.
In industrial applications, the Mitsubishi FX5U-32MT/ES PLC is used in conveyors, packaging machinery, automated assembly lines, and production control panels. Its fast instruction execution supports precise sequencing, while transistor outputs ensure stable control of sensors and actuators. Integrated Ethernet and RS-485 ports enable communication with automation networks, making it suitable for scalable and connected control architectures.
The Mitsubishi FX5U-32MT/ES PLC delivers reliable control performance within defined electrical and environmental limits. With FLASH-based memory, controlled power consumption, and standardized I/O capacity, it supports long-term panel-mounted operation. As part of the Mitsubishi FX Series, this PLC reflects Mitsubishiβs established engineering standards and is well suited for industrial automation applications across India.
