FX3UC-16MT/D - Mitsubishi Programmable Controllers Melsec
Mitsubishi FX3UC-16MT/D PLC operates on 24V DC, offers 64K steps memory, eight inputs, eight transistor outputs for industrial automation. Manufactured by Mitsubishi, this Mitsubishi PLC belongs to the FX Series and supports EEPROM program memory, 256 local I/O points, expandable architecture, SINK transistor output logic, 65 ns LD cycle time, 6 W power consumption, IP10 protection, and operation up to 55Β°C.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3UC-16MT/D |
FX3UC-16MT/D Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3UC |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 64K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 8 |
| Integrated Digital Outputs | 8 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 384 |
| Expandable | YES |
| Cycle Time LD (ns) | 65 |
| Cycle Time MOV (ns) | 642 |
| Power Consumption (W) | 6 |
| Buffer Battery | YES |
| Protection Class | IP10 |
| Max. Ambient Temperature (Β°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 74 |
| Weight (kg) | 0,2 |
| Width (mm) | 34 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,LR,RINA |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3UC-16MT/D PLC is a compact programmable logic controller designed for industrial automation applications requiring stable DC operation. This Mitsubishi FX3UC-16MT/D PLC uses a 24V DC power supply and provides 64K steps program memory stored in EEPROM for data retention. It includes eight digital inputs and eight transistor outputs with SINK logic, supporting up to 256 local I/O points. The controller is part of the Mitsubishi FX Series and aligns with MELSEC-F system architecture.
In industrial environments, the Mitsubishi FX3UC-16MT/D PLC is commonly used in conveyors, packaging lines, assembly stations, and small automation cells. Its fast instruction execution supports precise control sequences, while transistor outputs enable reliable switching for sensors and actuators. The expandable I/O structure allows integration into growing automation systems, making it suitable for production lines that require consistent logic performance and controlled power consumption.
The Mitsubishi FX3UC-16MT/D PLC delivers dependable control performance within industrial automation systems where space, stability, and memory reliability matter. With EEPROM-based memory, defined I/O capacity, and controlled power usage, it supports long-term operation in panel-mounted installations. As part of the Mitsubishi FX Series, this PLC reflects Mitsubishiβs established standards for control hardware used across industrial automation environments in India.
