FX3UC-16MR/DS-T - Mitsubishi Programmable Controllers Melsec
Mitsubishi FX3UC-16MR/DS-T PLC uses 24 V DC power, 64K steps program memory, and relay outputs for industrial control systems. This controller from Mitsubishi under the Mitsubishi PLC category belongs to the MELSEC-F Series, supporting 8 digital inputs, 8 digital outputs, 256 local I/O points, expandable architecture, buffer battery support, and IP10 protection.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3UC-16MR/DS-T |
FX3UC-16MR/DS-T Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3UC |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 64K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 8 |
| Integrated Digital Outputs | 8 |
| Output Type | RELAY |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 384 |
| Expandable | YES |
| Cycle Time LD (ns) | 65 |
| Cycle Time MOV (ns) | 642 |
| Power Consumption (W) | 6 |
| Buffer Battery | YES |
| Protection Class | IP10 |
| Max. Ambient Temperature (°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 74 |
| Weight (kg) | 0,25 |
| Width (mm) | 34 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3UC-16MR/DS-T PLC is a compact programmable logic controller designed for structured industrial automation control. The Mitsubishi FX3UC-16MR/DS-T PLC provides 64K program memory, operates on 24 V DC power, and uses relay outputs for stable signal switching. It belongs to the MELSEC-F Series and is used as a control unit within Mitsubishi PLC-based automation systems.
In industrial environments, the Mitsubishi FX3UC-16MR/DS-T PLC is commonly applied in conveyors, packaging machines, assembly stations, and coordinated production lines. Its expandable I/O structure supports flexible system layouts, while relay-based outputs allow reliable control of actuators and field devices in electrically diverse installations.
The Mitsubishi FX3UC-16MR/DS-T PLC reflects Mitsubishi’s standardized PLC engineering focused on reliability and long-term operation. With defined electrical specifications, buffer battery support, and certified compliance, this PLC is suitable for continuous industrial automation use. It integrates consistently within MELSEC-F control architectures used across manufacturing facilities.
