FX3U-64MT/DS - Mitsubishi Programmable Controllers Melsec
Technical Specifications of Mitsubishi Mitsubishi Programmable Controllers Melsec FX3U-64MT/DS:
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3U-64MT/DS |
FX3U-64MT/DS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3U |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 64K STEPS |
| Program Memory Unit | RAM |
| Integrated Digital Inputs | 32 |
| Integrated Digital Outputs | 32 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 384 |
| Expandable | YES |
| Cycle Time LD (ns) | 65 |
| Cycle Time MOV (ns) | 642 |
| Power Consumption (W) | 40 |
| Buffer Battery | YES |
| Protection Class | IP10 |
| Max. Ambient Temperature (ยฐC) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 86 |
| Weight (kg) | 1 |
| Width (mm) | 220 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
Equipped with a motor power of 0.55 hp (0.37 kW) and a stable nominal output current of 2.4 A, the FX3U-80MT/DS is optimized for seamless machine control. Its 1 RJ45 connector simplifies Ethernet-based integration, while its cabinet mount form and IP20 protection ensure reliable performance in challenging environments. This Mitsubishi PLC is engineered for users requiring flexibility, high-speed operation, and robust connectivity in demanding automation setups.
Supporting a switching frequency range of 2 to 16 kHz and a maximum output voltage of 240 V, the Mitsubishi FX3U-80MT/DS maintains efficient control across a wide spectrum of industrial loads. It performs reliably within ambient temperatures of -10ยฐC to 40ยฐC without derating, and up to 60ยฐC with minor adjustments. This model is a trusted choice in sectors such as packaging, automotive, and high-speed manufacturing where performance, expandability, and uptime matter most. For more detailed technical information, visit the official Mitsubishi FX3U-80MT/DS product page.
