FX3U-48MT/DS - Mitsubishi Programmable Controllers Melsec
The Mitsubishi FX3U-48MT/DS PLC uses 24V DC power, offers 64K RAM memory, and provides transistor outputs for industrial automation. Manufactured by Mitsubishi, this controller belongs to the Mitsubishi PLC lineup for control applications. It supports 24 digital inputs, 24 digital outputs, expandable I/O capacity, battery-backed memory, IP10 protection, and is part of the FX series.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3U-48MT/DS |
FX3U-48MT/DS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3U |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 64K STEPS |
| Program Memory Unit | RAM |
| Integrated Digital Inputs | 24 |
| Integrated Digital Outputs | 24 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 384 |
| Expandable | YES |
| Cycle Time LD (ns) | 65 |
| Cycle Time MOV (ns) | 642 |
| Power Consumption (W) | 35 |
| Buffer Battery | YES |
| Protection Class | IP10 |
| Max. Ambient Temperature (Β°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 86 |
| Weight (kg) | 0,85 |
| Width (mm) | 182 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,KR,LR,NK,RINA |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3U-48MT/DS PLC is a programmable logic controller designed for structured industrial automation systems. This Mitsubishi FX3U-48MT/DS PLC operates on 24V DC supply, includes 64K steps RAM program memory, and integrates 24 inputs and 24 transistor outputs. It is part of the MELSEC-F FX series and supports both local and remote I/O expansion for scalable control designs.
The Mitsubishi FX3U-48MT/DS PLC is used in conveyors, packaging machines, assembly stations, and automated production equipment. Transistor outputs allow high-speed signal switching, while fast instruction execution supports stable machine cycles. Expandable architecture enables engineers to add I/O and communication modules as control requirements increase across industrial installations.
The Mitsubishi FX3U-48MT/DS PLC reflects Mitsubishi Electricβs long-established FX platform used across manufacturing environments. Defined electrical ratings, environmental limits, and certified compliance support dependable long-term operation. This PLC is selected where consistent control performance, system expansion capability, and compatibility within Mitsubishi automation systems are required.
