FX3U-16MT/ES - Mitsubishi Programmable Controllers Melsec
The Mitsubishi FX3U-16MT/ES PLC operates on 100–240V AC power with 64K RAM memory and eight I/O transistor outputs control. Manufactured by Mitsubishi, this PLC is part of the Mitsubishi PLC portfolio designed for scalable automation control. It supports SINK transistor outputs, high-speed processing, expandable I/O architecture, battery-backed memory, and belongs to the FX series.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3U-16MT/ES |
FX3U-16MT/ES Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3U |
| Power Supply (V) | 100-240 |
| Current Type | AC |
| Program Memory | 64K STEPS |
| Program Memory Unit | RAM |
| Integrated Digital Inputs | 8 |
| Integrated Digital Outputs | 8 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 256 |
| Local + Remote I/O Points | 384 |
| Expandable | YES |
| Cycle Time LD (ns) | 65 |
| Cycle Time MOV (ns) | 642 |
| Power Consumption (W) | 30 |
| Buffer Battery | YES |
| Protection Class | IP10 |
| Max. Ambient Temperature (°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 86 |
| Weight (kg) | 0,6 |
| Width (mm) | 130 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,KR,LR,NK,RINA |
| EAC | NON-COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3U-16MT/ES PLC is a programmable logic controller designed for industrial automation control systems. This Mitsubishi FX3U-16MT/ES PLC uses 100–240V AC power, includes 64K steps RAM program memory, and provides 8 digital inputs and 8 digital outputs in a compact base unit. It belongs to the MELSEC-F FX series and supports extensive local and remote I/O expansion for flexible system design.
The Mitsubishi FX3U-16MT/ES PLC is commonly used in conveyors, packaging machines, automated assembly lines, and panel-based control applications. Integrated digital I/O enables direct connection to sensors and actuators, while fast instruction execution supports stable and predictable machine operation. Expandability allows additional modules to be added as automation requirements grow, without changing the main PLC.
The Mitsubishi FX3U-16MT/ES PLC is built on Mitsubishi Electric’s established FX platform, offering consistent electrical performance and long-term operational stability. Certified compliance, defined operating limits, and support for expansion modules make this PLC suitable for continuous industrial use. It is selected for reliable control, system scalability, and compatibility within Mitsubishi PLC-based automation environments.
