FX3S-14MT/DS - Mitsubishi Programmable Controllers Melsec
Mitsubishi FX3S-14MT/DS PLC uses 24 V DC power with 16K step memory and transistor outputs for compact control applications. This Mitsubishi PLC belongs to the FX Series and includes 8 digital inputs, 6 digital outputs, SINK logic, EEPROM program memory, 210 ns LD cycle time, IP10 protection, and 6.5 W power consumption.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3S-14MT/DS |
FX3S-14MT/DS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3S |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 16K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 8 |
| Integrated Digital Outputs | 6 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 30 |
| Local + Remote I/O Points | 30 |
| Expandable | NO |
| Cycle Time LD (ns) | 210 |
| Cycle Time MOV (ns) | 500 |
| Power Consumption (W) | 6,5 |
| Buffer Battery | NO |
| Protection Class | IP10 |
| Max. Ambient Temperature (Β°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 49 |
| Weight (kg) | 0,22 |
| Width (mm) | 60 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
Mitsubishi FX3S-14MT/DS PLC is a compact programmable logic controller designed for basic industrial automation tasks. The Mitsubishi FX3S-14MT/DS PLC offers 16K step EEPROM memory, 24 V DC operation, and transistor output configuration in a small footprint. It belongs to the FX Series and supports stable logic control for panel-based automation systems.
In industrial applications, the Mitsubishi FX3S-14MT/DS PLC is used in conveyors, small packaging machines, assembly fixtures, and standalone automation units. Its fixed I/O structure supports predictable signal handling, while transistor outputs provide fast switching for sensors and actuators. The controller suits environments where space efficiency and consistent cycle timing are required.
The Mitsubishi FX3S-14MT/DS PLC delivers reliable operation with defined electrical specifications and compliance with international standards. Simple architecture, stable processing performance, and Mitsubishi build quality make it suitable for long-term industrial use. The FX3S-14MT/DS PLC remains a dependable choice for entry-level automation control systems.
