FX3S-10MT/ES - Mitsubishi Programmable Controllers Melsec
The Mitsubishi FX3S-10MT/ES PLC operates on 100โ240V AC with 16K EEPROM memory and fixed transistor I/O for basic automation. Manufactured by Mitsubishi, this PLC belongs to the Mitsubishi PLC range used in compact industrial control systems. It provides 6 digital inputs, 4 transistor outputs, SINK logic, non-expandable I/O, IP10 protection, and is part of the FX series.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3S-10MT/ES |
FX3S-10MT/ES Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3S |
| Power Supply (V) | 100-240 |
| Current Type | AC |
| Program Memory | 16K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 6 |
| Integrated Digital Outputs | 4 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 30 |
| Local + Remote I/O Points | 30 |
| Expandable | NO |
| Cycle Time LD (ns) | 210 |
| Cycle Time MOV (ns) | 500 |
| Power Consumption (W) | 19 |
| Buffer Battery | NO |
| Protection Class | IP10 |
| Max. Ambient Temperature (ยฐC) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 75 |
| Weight (kg) | 0,3 |
| Width (mm) | 60 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3S-10MT/ES PLC is a compact programmable logic controller designed for entry-level industrial automation. This Mitsubishi FX3S-10MT/ES PLC uses 100โ240V AC power, includes 16K steps EEPROM program memory, and supports fixed digital I/O with transistor outputs. It belongs to the MELSEC-F FX series and is selected for simple control tasks where expansion is not required.
The Mitsubishi FX3S-10MT/ES PLC is commonly applied in small conveyors, basic packaging machines, simple assembly stations, and standalone automation panels. Fixed I/O architecture ensures predictable operation, while defined scan times support stable sequence control. Moderate power consumption and compact dimensions make it suitable for space-limited industrial control enclosures.
The Mitsubishi FX3S-10MT/ES PLC complies with global industrial standards and integrates reliably within Mitsubishi Electric automation systems. With certified approvals, defined electrical characteristics, and FX series consistency, it supports dependable long-term operation. Engineers rely on this PLC for stable performance, straightforward installation, and reliable control in basic industrial automation applications.
