FX3GE-24MT/DS - Mitsubishi Programmable Controllers Melsec
The Mitsubishi FX3GE-24MT/DS PLC operates on 24V DC with 32K EEPROM memory and transistor outputs for industrial automation. This Mitsubishi FX3GE-24MT/DS PLC is manufactured by Mitsubishi and classified under Mitsubishi PLC platforms used in control panels. It provides 14 digital inputs, 10 digital outputs, 2 analogue inputs, one Ethernet port, expandable I/O up to 256 points, IP10 protection, and belongs to the FX series PLC family.
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3GE-24MT/DS |
FX3GE-24MT/DS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3GE |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 32K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 14 |
| Integrated Digital Outputs | 10 |
| Integrated Analogue Inputs | 2 |
| Output Type | TRANSISTOR |
| Output Logic | SINK |
| Local I/O Points | 128 |
| Local + Remote I/O Points | 256 |
| Expandable | YES |
| Cycle Time LD (ns) | 210 |
| Cycle Time MOV (ns) | 500 |
| Ethernet Port | 1 |
| Power Consumption (W) | 32 |
| Buffer Battery | OPTION |
| Protection Class | IP10 |
| Max. Ambient Temperature (°C) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 86 |
| Weight (kg) | 0,6 |
| Width (mm) | 130 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The Mitsubishi FX3GE-24MT/DS PLC is a programmable logic controller designed for industrial automation control applications. This Mitsubishi FX3GE-24MT/DS PLC operates using 24V DC power, includes 32K steps EEPROM program memory, and integrates transistor-based digital I/O with SINK logic. It belongs to the MELSEC-F FX series and is used where compact size and integrated communication are required.
In industrial environments, the Mitsubishi FX3GE-24MT/DS PLC is applied in conveyors, packaging machines, automated assembly lines, and process control systems. Its built-in Ethernet port supports networked automation, while integrated analogue inputs allow basic signal processing. The PLC enables stable machine operation with predictable scan timing and defined I/O capacity for coordinated industrial processes.
The Mitsubishi FX3GE-24MT/DS PLC aligns with Mitsubishi Electric control standards and international compliance requirements. With certified approvals, defined memory capacity, and FX series compatibility, it is suitable for continuous industrial use. This PLC is trusted by engineers for reliable operation, structured expansion capability, and seamless integration into Mitsubishi PLC-based automation architectures.
