FX3GE-24MR/DS - Mitsubishi Programmable Controllers Melsec
Technical Specifications of Mitsubishi Mitsubishi Programmable Controllers Melsec FX3GE-24MR/DS:
| Brand | Mitsubishi |
| Product Type | PLC(Programmable Logic Controller) |
| Product | FX3GE-24MR/DS |
FX3GE-24MR/DS Mitsubishi Programmable Controllers Melsec Technical Specifications
| Specification | Value |
|---|---|
| Type | FX3GE |
| Power Supply (V) | 24 |
| Current Type | DC |
| Program Memory | 32K STEPS |
| Program Memory Unit | EEPROM |
| Integrated Digital Inputs | 14 |
| Integrated Digital Outputs | 10 |
| Integrated Analogue Inputs | 2 |
| Output Type | RELAY |
| Local I/O Points | 128 |
| Local + Remote I/O Points | 256 |
| Expandable | YES |
| Cycle Time LD (ns) | 210 |
| Cycle Time MOV (ns) | 500 |
| Ethernet Port | 1 |
| Power Consumption (W) | 32 |
| Buffer Battery | OPTION |
| Protection Class | IP10 |
| Max. Ambient Temperature (ยฐC) | 55 |
| Series | MELSEC-F SERIES |
| Depth (mm) | 86 |
| Weight (kg) | 0,6 |
| Width (mm) | 130 |
| Height (mm) | 90 |
| CE | COMPLIANT |
| EAC | NON-COMPLIANT |
| UL/cUL | COMPLIANT |
| UKCA | COMPLIANT |
The FX3GE-24MR/DS is part of the advanced MELSEC-F Series by Mitsubishi Electric, engineered for compact control with powerful processing. It features a 24V DC power supply and supports up to 32K steps of EEPROM-based program memory, ensuring long-term data retention without risk of loss. With 14 digital inputs, 10 relay-type digital outputs, and 2 analog inputs, this PLC offers the flexibility required for multi-signal operations in real-time automation processes.
The FX3GE-24MR/DS PLC stands out with its ultra-fast response, delivering a 210 ns cycle time</strong for LD instructions and 500 ns for MOV commands. It is capable of managing 128 local I/O points and can scale up to 256 remote I/O points, making it an excellent choice for expanding systems. With built-in Ethernet connectivity, it allows seamless integration into industrial networks, while its optional RS-485 support provides additional communication versatility. Despite its compact footprint (130mm ร 90mm ร 86mm), itโs packed with power and maintains IP10 protection, an operating temperature tolerance up to 55ยฐC, and global certifications like CE, UL/cUL, and UKCA compliance.
Backed by Mitsubishiโs reputation for innovation and support, the FX3GE-24MR/DS PLC is trusted by automation professionals in sectors such as packaging, food processing, machine tools, and smart factories. Its reliable performance, flexible expandability, and international compliance make it a go-to controller for automation system integrators and maintenance engineers. To explore all specs and datasheets, visit the official Mitsubishi Electric page for FX3GE-24MR/DS.
The FX3GE-24MR/DS PLC is widely used in automated systems where quick logic decisions and multi-signal processing are required. In small to mid-sized machine automation, it handles tasks like motor control, conveyor sequencing, sensor feedback interpretation, and real-time condition monitoring. Engineers appreciate its compact size, making it suitable for panels with limited space.
Thanks to its Ethernet port and fast cycle time, it fits perfectly in SCADA systems, packaging machinery, bottling lines, and CNC machine tool environments. For Indian maintenance engineers working in dynamic manufacturing plants, the FX3GE-24MR/DS simplifies complex automation through intuitive programming and scalable hardware. Engineering students learning automation also benefit from its hands-on programmability and modular structure.
Whether youโre automating a standalone machine or integrating with higher-level control systems, the Mitsubishi FX3GE-24MR/DS PLC delivers performance, speed, and long-term reliability. Its wide usage across industries ensures you'll find documentation, tutorials, and expert help easily available, reinforcing trust in both product and brand.
