FX3G-14MT/ESS - Mitsubishi Programmable Controllers Melsec

Name: Mitsubishi FX3G-14MT/ESS
Brand: Mitsubishi
SKU: FX3G-14MT/ESS
Rating: 4.6 (4 reviews)

Technical Specifications of Mitsubishi Mitsubishi Programmable Controllers Melsec FX3G-14MT/ESS:

Brand	Mitsubishi
Product Type	PLC(Programmable Logic Controller)
Product	FX3G-14MT/ESS

FX3G-14MT/ESS Mitsubishi Programmable Controllers Melsec Technical Specifications

Specification	Value
Type	FX3G
Power Supply (V)	100-240
Current Type	AC
Program Memory	32K STEPS
Program Memory Unit	EEPROM
Integrated Digital Inputs	8
Integrated Digital Outputs	6
Output Type	TRANSISTOR
Output Logic	SOURCE
Local I/O Points	128
Local + Remote I/O Points	256
Expandable	YES
Cycle Time LD (ns)	210
Cycle Time MOV (ns)	500
Power Consumption (W)	31
Buffer Battery	OPTION
Protection Class	IP10
Max. Ambient Temperature (°C)	55
Series	MELSEC-F SERIES
Depth (mm)	86
Weight (kg)	0,5
Width (mm)	90
Height (mm)	90
CE	COMPLIANT
Shipping Approvals	ABS,BV,DNV GL,KR,LR,NK,RINA
EAC	NON-COMPLIANT
UL/cUL	COMPLIANT
UKCA	COMPLIANT

The FX3G-14MT/ESS is a feature-rich PLC by Mitsubishi Electric, known for its exceptional blend of performance, scalability, and compact design. Powered by a versatile 100–240V AC supply, it utilizes a transistor-based output system with source logic, ideal for fast-switching applications. It comes equipped with 8 integrated digital inputs and 6 digital outputs, ensuring responsive and accurate signal processing in machine control systems.

The controller supports up to 128 local I/O points and can be expanded to 256 I/O points when remote modules are added. With 32K steps of EEPROM program memory, the FX3G-14MT/ESS ensures long-term data retention even in power-loss scenarios. Its cycle time of 210 ns for LD instructions and 500 ns for MOV operations enables real-time logic execution, which is critical for time-sensitive automation tasks. The compact dimensions of 90 mm (W) × 90 mm (H) × 86 mm (D) make it suitable for space-constrained panels without sacrificing functionality.

This MELSEC-F Series PLC is built for industrial durability, supporting operations in ambient temperatures up to 55°C and rated with IP10 protection. Engineers value its optional buffer battery for data protection and its internationally recognized certifications including CE, UL/cUL, UKCA, and marine approvals like ABS, DNV GL, and RINA. Backed by Mitsubishi’s global reliability and support infrastructure, the FX3G-14MT/ESS PLC is a proven choice for Indian manufacturers and OEMs seeking scalable control. For complete documentation and product downloads, visit the official Mitsubishi Electric website.

The FX3G-14MT/ESS PLC is widely used in automation systems where quick switching, compact size, and stable performance are essential. Typical applications include packaging machines, labeling systems, textile automation, and compact material handling setups. The fast logic cycle and transistor outputs make it ideal for systems requiring high-speed actuation like solenoid valves and stepper motor control.

Maintenance engineers across Indian industries prefer the FX3G-14MT/ESS because it balances advanced functionality with simplicity. It enables quick diagnostics, reliable performance under harsh conditions, and integrates seamlessly with HMI and SCADA systems. Thanks to its compact footprint, it fits easily into standard panels, saving both space and wiring effort—making it perfect for retrofitting older machines as well.

For students and junior engineers learning programmable logic control, the FX3G-14MT/ESS is also a great educational platform. Its clear I/O structure, modular expandability, and industry-standard programming logic make it a practical entry point into real-world automation. Whether you're designing from scratch or optimizing an existing process, this PLC delivers precision, speed, and long-term dependability.
