Leuze PRK53CL1.TT3/LG-M8 | 50148164
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | PRK53CL1.TT3/LG-M8 |
Leuze Light/dark switching retro-reflective photoelectric sensor PRK53CL1.TT3/LG-M8 - 50148164 Technical Specifications:
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Reflection principle |
| Application | Detection of highly transparent bottles Detection of transparent films |
| Special version | Autocollimation HYGIENE design Tracking function |
| Sensing Distance | 0 ... 0.4 m |
| Beam path | Collimated |
| Light source | Laser, Red |
| Wavelength | 650 nm |
| Type of light spot geometry | Round |
| Supply voltage UB | 10 ... 30 V, DC, Incl. residual ripple |
| Switching Output 1 | Transistor, Push-pull |
| Switching principle | IO-Link / light switching (PNP)/dark switching (NPN) |
| Switching Output 2 | Transistor, Push-pull |
| Switching principle | Dark switching (PNP)/light switching (NPN) |
| Switching frequency | 3,000 Hz |
| Response time | 0.17 ms |
| Function | Signal IN Signal OUT Voltage supply |
| Type of connection | Connector |
| Thread size | M8 |
| Type | Male |
| Material | Stainless steel |
| No. of pins | 4 -pin |
| Encoding | - |
| Dimension (W x H x L) | 14 mm x 35.4 mm x 20.4 mm |
| Housing material | Stainless steel |
| Metal housing | AISI 316L, DIN X2CrNiMo17132, W.No1.4404 |
| Lens cover material | Plastic (PMMA+) with scratch-resistant Indium protective coating |
| Housing color | Silver |
| Type of display | LED |
| Operational controls | Teach button |
| Ambient temperature, operation | -40 ... 70 °C |
| Ambient temperature, storage | -40 ... 70 °C |
| Degree of protection | IP 67/IP 68/IP 69K |
The Leuze PRK53CL1.TT3/LG-M8 Photoelectric Sensor features a rugged stainless steel housing with dimensions of 14 mm x 35.4 mm x 20.4 mm, engineered specifically for harsh industrial environments including food and beverage lines. It operates on the reflection principle using a collimated red laser beam at 650 nm, delivering exceptional accuracy for detecting even highly transparent objects such as PET bottles or plastic films. The sensor supports a sensing distance of up to 0.4 meters and boasts a lightning-fast response time of just 0.17 ms, making it ideal for high-speed automation tasks.
Equipped with dual transistor push-pull outputs, the PRK53CL1.TT3/LG-M8 supports both light switching (PNP) and dark switching (NPN) modes, offering flexible integration via IO-Link. The connector is a durable 4-pin male M8 with IP67, IP68, and IP69K protection ratings, ensuring long-term reliability even under exposure to water jets, steam, or chemicals. The inclusion of a Teach button and LED display enhances ease of setup and maintenance, while the scratch-resistant PMMA+ lens ensures optical clarity over time. Operating safely across a wide temperature range of -40 to +70 °C, this sensor is trusted for continuous duty in bottling, filling, and hygienic packaging lines.
Backed by the globally respected Leuze brand, the PRK53CL1.TT3/LG-M8 stands out for its autocollimation capability, calibrated Y-axis tracking, and precise beam control—making it a reliable solution where consistency, hygiene, and detection accuracy are critical. Visit official Leuze page for PRK53CL1.TT3/LG-M8 for datasheets, CAD drawings, and more.
The Leuze PRK53CL1.TT3/LG-M8 Photoelectric Sensor is purpose-built for critical applications such as detecting transparent bottles, plastic wraps, and glass surfaces moving on high-speed conveyors. Its laser-based precision and autocollimation design allow it to maintain consistent detection even when objects are curved, slippery, or partially covered—problems that confuse ordinary sensors.
Maintenance engineers in bottling or food-grade packaging facilities often struggle with false triggers or missed detections due to reflection issues. This model solves that by using a sharp collimated laser beam with round spot geometry, improving object focus and reducing background noise. Its hygienic-grade stainless steel housing ensures that cleaning and washdowns won’t affect sensor performance.
Whether you're installing a new line or upgrading sensors in your existing setup, the Leuze PRK53CL1.TT3/LG-M8 Photoelectric Sensor offers a combination of detection reliability, build quality, and control interface flexibility that makes it a top choice for automation engineers across India. The photoelectric sensor from Leuze delivers dependable performance in every cycle, every shift, every day.
