Leuze M12, male connector with four pins retro-reflective sensor PRK25CL1.1/2N-M8 - 50139662 Technical Specifications:
Specification
Value
Design
Cubic
Operating principle
Reflection principle
Application
-
Special version
-
Sensing Distance
0.2 ... 20 m, With reflector TK(S) 100x100
Beam path
Collimated
Light source
Laser, Red
Wavelength
650 nm
Type of light spot geometry
elliptic
Supply voltage UB
10 ... 30 V, DC, Incl. residual ripple
Switching Output 1
Transistor, NPN
Switching principle
Light switching
Switching Output 2
Transistor, NPN
Switching principle
Dark switching
Switching frequency
2,500 Hz
Response time
0.33 ms
Function
Signal OUT
Voltage supply
Type of connection
Connector
Thread size
M8
Type
Male
Material
PUR
No. of pins
4 -pin
Encoding
-
Dimension (W x H x L)
15 mm x 42.7 mm x 30 mm
Housing material
Plastic
Metal housing
ABS
Lens cover material
Plastic
Housing color
Red
Type of display
LED
Operational controls
270Β° potentiometer
Ambient temperature, operation
-40 ... 60 Β°C
Ambient temperature, storage
-40 ... 70 Β°C
Degree of protection
IP 67 / IP 69K
Get A Quote for Leuze M12, male connector with four pins retro-reflective sensor PRK25CL1.1/2N-M8 part no: 50139662 at the best price. Here are the brief Technical Specifications of PRK25CL1.1/2N-M8, 50139662 are Cubic, Design Reflection principle, 15 mm x 42.7 mm x 30 mm Dimension, Laser, Red Light source, Transistor, NPN Switching Outputs 1, Light switching Switching principle, 10 ... 30 V, DC, Incl. residual ripple Supply voltage UB, 0.2 ... 20 m, With reflector TK(S) 100x100 Sensing Distance, 4 -pin No. of pins, Plastic Housing material, IP 67 / IP 69K degree of protection. It's Time to get a Quote for your requirement of Leuze M12, male connector with four pins retro-reflective sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
