ODS10L1-25M.8/LAK,200-M12: 50129536 - Leuze Laser Red Sensor
Technical Specifications of Leuze Laser Red Sensor ODS10L1-25M.8/LAK,200-M12:
| Brand | Leuze |
| Product Type | Optical Distance Sensor |
| Product | ODS10L1-25M.8/LAK,200-M12 |
Leuze Laser Red Sensor ODS10L1-25M.8/LAK,200-M12, 50129536 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 25 mm x 65 mm x 55 mm |
| Switching Output 1 | Transistor, Push-pull |
| Measurement range | 100 ... 25,000 mm, In combination with cooperative target reflective tape 7-A |
| Supply voltage UB | 18 ... 30 V, DC |
| Analog output type | Configurable, factory setting: current |
| Connection type | Cable with connector, Turning, 90Β° |
| Thread size | M12 |
| No. of pins | 5 -pin |
| Housing material | Plastic |
| Lens cover material | Glass |
| Degree of protection | IP 67 |
IndMALL Offers Leuze Laser Red Sensor, ODS10L1-25M.8/LAK,200-M12, 50129536 at economical Choices. Product Tech Specs of ODS10L1-25M.8/LAK,200-M12 includes Glass, Plastic, 5 -pin, M12, Cable with connector, Turning, 90Β°, IP 67, 18 ... 30 V, DC & 100 ... 25,000 mm, In combination with cooperative target reflective tape 7-A. And It Includes Laser, Red, Transistor, Push-pull & 25 mm x 65 mm x 55 mm. Now's the Time to Secure a Quote for your requirement of 50129536. Trust in our superior pricing and more dedicated support over other Distributors.
