Leuze MSI-SR5B-02 | 547953
Technical Specifications of Leuze MSI-SR5B-02 547953:
| Brand | Leuze |
| Product Type | Safety Relay |
| Product | MSI-SR5B-02 |
Leuze Spring Cage Terminal Safety Relay MSI-SR5B-02, 547953 Technical Specifications:
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 22.5 mm x 111 mm x 114.1 mm |
| Functions | Automatic start/restart Contactor monitoring (EDM) Cross circuit monitoring Double sensor monitoring Start/restart interlock (RES), selectable |
| Restart | Automatic Manual |
| Type of Terminal | Spring-cage terminal |
| No. of pins | 16 -pin |
| Connection 1 Function | Connection to device |
| Number of connections | 1 Piece(s) |
| Response Time | - |
| Evaluation of the inputs | - |
| Input current | 150 mA |
| Supply Voltage UB | 24 V, DC, -20 ... 20 % |
| Power consumption, max | 4.8 W, For 24 V, plus output load |
| Switching Output 1 | Relay, NO |
| Type of fastening | Snap-on mounting |
| Housing Material | Plastic |
| Housing Color | Gray |
| Ambient Temperature, Operation | 0 ... 55 Β°C |
| Ambient Temperature, Storage | -25 ... 70 Β°C |
| Degree of protection | IP 20 (terminals) IP 40 (housing) |
Please speak to our Technical Engineer for Leuze Spring Cage Terminal Safety Relay MSI-SR5B-02 547953 at attractive prices. Technical Specs Summary of MSI-SR5B-02 includes dimensions of 22.5 mm x 111 mm x 114.1 mm, it offers automatic start/restart functionality, contactor monitoring, cross circuit monitoring, and double sensor monitoring.. And Special Features Are Suitable for both automatic and manual operations, it operates within a wide temperature range and offers IP 20 (terminals) and IP 40 (housing) protection. Match Your Needs with a Quote for your requirement of Leuze Spring Cage Terminal Safety Relay. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
