Leuze MSI 420-01 Safety Controller
The Leuze MSI 420-01 Safety Controller (Part No: 50132986 ) offers a Monitoring of safety functions, 16 IN, 4 OUT, 4 programmable I/O
, Screw terminal, 32 -pin . Manufactured by Leuze under the Leuze Safety Controller category, this model belongs to the MSI Series.
| Brand | Leuze |
| Product Type | Safety Controller |
| Product | MSI 420-01 |
Leuze MSI 420-01 Safety Controller β Technical Specifications
| Specification | Value |
|---|---|
| Dimension (W x H x L) | 45 mm x 96.5 mm x 121 mm |
| Application | Monitoring of safety functions |
| Number of safe I/Os | 16 IN, 4 OUT, 4 programmable I/O |
| Supply voltage UB | 24 V, DC, -30 ... 25 % |
| Power consumption, max. | 3.3 W |
| Number of outputs | 4 Piece(s) |
| Type of digital output | Transistor |
| Number of inputs | 16 Piece(s) |
| Interface Type | Ethernet, USB |
| Number of connections | 3 Piece(s) |
| Con:1 Function | Signal IN Signal OUT Voltage supply |
| Type of connection | Terminal |
| Type of terminal | Screw terminal |
| No. of pins | 32 -pin |
| Con:2 Function | Configuration interface |
| Type of connection | USB |
| Housing color | Gray |
| Type of fastening | Snap-on mounting |
| Ambient temperature, operation | -25 ... 65 Β°C |
| Ambient temperature, storage | -25 ... 70 Β°C |
| Degree of protection | IP 20 |
Get Quote for Leuze Ethernet Interface Safety Controller MSI 420-01 50132986 at best prices. The Main Technical Parameters of MSI 420-01 are 45 mm x 96.5 mm x 121 mm Dimensions, 20 IN, 4 OUT Number of Safe I/Os, 24 V, DC, -30 ... 25 % Supply Voltage, 3.3 W Power Consumption, Ethernet, USB Interface Type, Terminal Connection Screw terminal, 32 -pin, Snap-on mounting, Gray Housing color, IP 20 degree of protection. It's Time to get a Quote for your requirement of Leuze Ethernet Interface Safety Controller.
