Leuze MLC310R20-150 Safety Light Curtain
| Brand | Leuze |
| Product Type | Safety Light Curtain |
| Model Number | MLC310R20-150 |
Leuze MLC310R20-150 Safety Light Curtain โ Technical Specifications
| Specification | Value |
|---|---|
| Series | MLC 300 |
| Device type | Receiver |
| Contains | 2x BT-NC sliding block |
| Application | Hand protection |
| Functions | Automatic start/restart, Transmission channel changeover |
| Resolution | 20 mm |
| Protective field height | 150 mm |
| Synchronization | Optical between transmitter and receiver |
| Protective circuit | Overvoltage protection, Short circuit protected |
| Supply voltage UB | 24 V, DC, -20 ... 20 % |
| Current consumption, max. | 150 mA |
| Number of safety-related switching outputs (OSSDs) | 2 Piece(s) |
| Safety related switching output Type | Safety-related switching output OSSD |
| Switching voltage high, min. | 18 V |
| Switching voltage low, max. | 2.5 V |
| Switching voltage, typ. | 22.5 V |
| Voltage type | DC |
| Current load, max. | 380 mA |
| Load inductivity | 2,000 ยตH |
| Load capacity | 0.03 ยตF |
| Residual current, max. | 0.002 mA |
| Voltage drop | 1.5 V |
| O/P 1: Switching Principle | 24 V switching |
| O/P 1: Switching Output | Transistor, PNP |
| O/P 2: Switching Principle | 24 V switching |
| O/P 2: Switching Output | Transistor, PNP |
| Response time | 4 ms |
| Restart delay time | 100 ms |
| Number of connections | 1 Piece(s) |
| Function | - |
| Type of connection | M12 Connector 5-pin |
| Type | Male |
| Dimension (W x H x L) | 29 mm x 216 mm x 35.4 mm |
| Housing material | Metal: Aluminum |
| Lens cover material | Plastic / PMMA |
| Material of end caps | Diecast zinc |
| Housing color | Yellow, RAL 1021 |
| Type of fastening | Groove mounting, Mounting brackets, Mounting on Device Column, Swivel mount |
| Type of display | LED |
| Number of LEDs | 2 Piece(s) |
| Degree of protection | IP 65 |
| Protection class | III |
| Ambient temperature, operation | 0 ... 50 ยฐC |
| Ambient temperature, storage | -30 ... 70 ยฐC |
| Relative humidity (non-condensing) | 0 ... 95 % |
| Net weight | 300 g |
The Leuze MLC310R20-150 Safety Light Curtain belongs to the MLC 300 series and is configured as a compact receiver unit for safeguarding machine access points. With a fine 20 mm resolution, it can detect small body parts like fingers and hands, making it highly effective for guarding areas where precision matters. The 150 mm protective height is suitable for small machine openings and workstations, especially in sectors like electronics assembly and light-duty packaging lines. It employs optical synchronization with its paired transmitter for seamless signal integration, and includes advanced features like automatic start/restart and channel changeover to meet stringent safety requirements.
The system operates on a reliable 24 V DC power supply with tolerance up to ยฑ20%, drawing a maximum of 150 mA. It delivers two OSSD outputs with PNP transistor switching and supports switching voltages up to 22.5 V. The ultra-fast response time of 4 ms ensures immediate signal transfer to stop machinery upon interruption. Built with a compact 29 mm x 216 mm x 35.4 mm aluminum housing, the unit connects via a 5-pin M12 male connector and features 2 LED indicators for quick status checks. Its robust construction includes a PMMA lens cover and diecast zinc end caps, all protected by an IP65-rated enclosure.
Weighing only 300 g, the MLC310R20-150 is ideal for installations requiring minimal space and easy maintenance. Designed to operate efficiently across 0 to 50ยฐC and resist up to 95% non-condensing humidity, this model is widely trusted by OEMs and plant engineers in clean, high-speed production environments. For certifications and integration manuals, visit the official Leuze website.
The Leuze MLC310R20-150 Safety Light Curtain is ideal for small-scale safety zones where hand-level detection is required without compromising on accuracy or speed. This model is commonly used in electronic component assembly units, desktop robotic arms, compact inspection systems, and laboratory-grade automation cells. Its compact dimensions and fast response time make it a practical choice for areas where full-height light curtains are unnecessary or physically restrictive.
Maintenance technicians in India find this model extremely easy to deploy due to its universal groove mounting, swivel brackets, and standard M12 connector. Junior engineers appreciate the two-LED status display that simplifies diagnostics, while system designers benefit from the channel-switching feature that eliminates interference in tight spaces. The optical sync eliminates the need for sync wiring, streamlining setup and reducing long-term servicing costs.
For engineers seeking a balance of reliability, compactness, and compliance, the Leuze MLC310R20-150 Safety Light Curtain offers a dependable solution. Contact us now for a tailored quote and get expert support for integrating this model into your safety system with maximum efficiency and value.
