Leuze MLC300T30-900 Safety Light Curtain
The Leuze MLC300T30-900 Safety Light Curtain (Part No: 68090309 ) offers a Hand protection, 900 mm protective height, M12 Connector 5-pin . Manufactured by Leuze under the Leuze Safety Light Curtain category, this model belongs to the ELC Series.
| Brand | Leuze |
| Product Type | Safety Light Curtain |
| Product | MLC300T30-900 |
Leuze MLC300T30-900 Safety Light Curtain β Technical Specifications
| Specification | Value |
|---|---|
| Series | MLC 300 |
| Device type | Transmitter |
| Contains | 2x BT-NC sliding block |
| Application | Hand protection |
| Resolution | 30 mm |
| Protective field height | 900 mm |
| Operating range | 0 ... 10 m |
| Synchronization | Optical between transmitter and receiver |
| Light source | LED, Infrared |
| Wavelength | 940 nm |
| Mean power of transmitter diode | 50 Β΅W |
| Transmitted-signal shape | Pulsed |
| Protective circuit | Overvoltage protection, Short circuit protected |
| Supply voltage UB | 24 V, DC, -20 ... 20 % |
| Current consumption, max. | 50 mA |
| Number of connections | 1 Piece(s) |
| Function | Machine interface |
| Type of connection | M12 Connector 5-pin |
| Type | Male |
| Dimension (W x H x L) | 29 mm x 966 mm x 35.4 mm |
| Housing material | Metal: Aluminum |
| Lens cover material | Plastic / PMMA |
| Material of end caps | Diecast zinc |
| Housing color | Yellow, RAL 1021 |
| Type of fastening | Groove mounting, Mounting brackets, Mounting on Device Column, Swivel mount |
| Type of display | LED |
| Number of LEDs | 2 Piece(s) |
| Degree of protection | IP 65 |
| Protection class | III |
| Ambient temperature, operation | 0 ... 55 Β°C |
| Ambient temperature, storage | -30 ... 70 Β°C |
| Relative humidity (non-condensing) | 0 ... 95 % |
| Net weight | 1,050 g |
The Leuze MLC300T30-900 belongs to the trusted MLC 300 series and is engineered to provide accurate hand protection with a 30 mm resolution and a protective field height of 900 mm. It operates reliably across a detection range of 0 to 10 meters, making it suitable for mid-range safety applications in packaging machines, press lines, and automated assembly stations. The unit uses a pulsed infrared LED light source at a wavelength of 940 nm, ensuring stable signal transmission even in variable lighting conditions.
Designed for efficient integration, the transmitter requires a 24 V DC power supply with Β±20% tolerance and consumes a maximum current of only 50 mA. It connects using a standard M12 5-pin male connector and synchronizes optically with the receiver, eliminating wiring complexity. Built-in protection circuits safeguard against overvoltage and short circuits, enhancing operational safety. A clear dual LED display with 2 indicators simplifies installation and alignment during commissioning.
Structurally, the MLC300T30-900 is housed in a durable aluminum enclosure with diecast zinc end caps and a transparent PMMA lens cover. Its compact design, measuring just 29 mm x 966 mm x 35.4 mm and weighing around 1,050 grams, fits easily into tight machine enclosures. With a robust IP65 protection rating, it withstands dusty and damp industrial environments. The transmitter supports versatile mounting options, including groove brackets and swivel mounts. With its proven performance, the Leuze MLC300T30-900 Safety Light Curtain is a trusted component across Indiaβs industrial automation sector.
The Leuze MLC300T30-900 Safety Light Curtain is ideally suited for machines that require precise hand protection across medium-sized access zones. It is commonly used in automated assembly lines, robotic arms, pick-and-place systems, and conveyor-based packaging machines where space is limited but safety cannot be compromised.
Maintenance teams appreciate the fast setup made possible by its optical synchronization and LED alignment indicators. Engineers benefit from the wide operating temperature range of 0Β°C to 55Β°C and compatibility with standard M12 connectors, reducing downtime during replacements or upgrades. With a 900 mm protective height, it covers large machine openings effectively without needing multiple sensors or curtains.
Whether you're retrofitting legacy machines or implementing new safety zones in automated setups, the MLC300T30-900 Safety Light Curtain from Leuze offers the ideal combination of precision, durability, and ease of integration. As a key player in industrial safety, this model helps companies across India meet safety regulations without sacrificing machine uptime or performance.
