Leuze LSE 55/44.H2O,5000 Photoelectric Sensor
The Leuze LSE 55/44.H2O,5000 Photoelectric Sensor (Part No: 50137740 ) offers a 0 ... 64 m operating range, Transistor, PNP output, 5000 mm PVC Cable 4 -wire . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LSE 55/44.H2O,5000 |
Leuze LSE 55/44.H2O,5000 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 55 Series |
| Operating principle | Throughbeam principle |
| Device type | Receiver |
| Operating range | 0 ... 64 m |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 20 mA |
| Number of digital switching outputs | 2 Piece(s) |
| Switching Output | Transistor, PNP |
| Switching Principle | Light switching/Dark switching |
| Switching frequency | 350 Hz |
| Response time | 1.43 ms |
| Readiness delay | 300 ms |
| Connection Function | Signal OUT Voltage supply |
| Type of Connection | 5000 mm PVC Cable |
| Number of conductors or Pins | 4 -wire |
| Dimension (W x H x L) | 14 mm x 35.5 mm x 25 mm |
| Housing material | Plastic Stainless steel |
| Lens cover material | Plastic with scratch-resistant Indium protective coating |
| Housing color | Silver |
| Type of display | LED |
| Ambient temperature | operation -30 ... 55 Β°C storage -30 ... 55 Β°C |
| Degree of protection | IP 67, IP 69K |
| Net weight | 60 g |
Obtain a Quote for Leuze 1.43 ms Response Time Through Beam Receiver Sensor LSE 55/44.H2O,5000 part no: 50137740 at economical prices. Specifications Overview for LSE 55/44.H2O,5000, reveals 55 series, Throughbeam principle
, Receiver device, 10 ... 30 V, DC power supply, 0 ... 20 mA current, 2 Piece(s) digital switching output, Transistor, PNP output, Light switching/Dark switching, 350 Hz frequency, 5000 mm PVC Cable, 4 -wire, 14 mm x 35.5 mm x 25 mm dimensions, Silver housing color, LED
display, IP 67, IP 69K degree of protection. Take the First Step with a Quote for your requirement of Leuze 1.43 ms Response Time Through Beam Receiver Sensor.
