Leuze ISS 230MM/44-10E Proximity Sensor
The Leuze ISS 230MM/44-10E Proximity Sensor (Part No: ) offers a 10 mm sensing distance, 10 ... 36 V, DC supply voltage, Transistor, PNP NO contact β Antivalent output, PVC Cable, 2,000mm Length connection, 4 -wire . Manufactured by Leuze under the Leuze Proximity Sensor category, this model belongs to the 180 & 240 Series.
| Brand | Leuze |
| Product Type | Proximity Sensor |
| Product | ISS 230MM/44-10E |
Leuze ISS 230MM/44-10E Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Series | 230 Series |
| Sensing Distance | 10 mm |
| Supply Voltage | 10 ... 36 V, DC |
| Number of digital switching outputs | e Piece(s) |
| Switching Current | 200 mA |
| Residual Current | 0.05 mA |
| Voltage drop | β€ 2 V |
| O/P 1: Switching Output | Transistor, PNP |
| O/P 1: Switching Principle | NO contact β Antivalent |
| O/P 2: Switching Output | Transistor, PNP |
| O/P 2: Switching Principle | NO contact β Antivalent |
| Switching frequency, max. | 1,000 Hz |
| Number of connections | 1 Piece(s) |
| Connection Function | Signal OUT Voltage supply |
| Type of Connection | PVC Cable, 2,000mm Length |
| Number of conductors or Pins | 4 -wire |
| Design | Cylindrical |
| Dimension (Γ x L) | 30 mm x 40.6 mm |
| Type of installation | Embedded |
| Housing material | Metal |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Housing color | Gray Silver |
| Standard measuring plate | 30 x 30 mmΒ², Fe360 |
| Number of LEDs | 1 Piece(s) |
| Ambient temperature | Operation: -25 ... 70 Β°C Storage: -30 ... 80 Β°C |
| Degree of protection | IP 67 |
Send Your Inquiry for Leuze 40.6 Length Cylindrical Switch ISS 230MM/44-10E part no: 50141486 with cost-effective solutions. Essential Technical Specs of ISS 230MM/44-10E, 50141486 are 230 series, 10 mm Sensing, 10 ... 36 V, DC power supply, e Piece(s) digital switching output, 200 mA current, Transistor, PNP, NO contact β Antivalent output, 1,000 Hz, 1 Piece(s) Connection, PVC Cable, 2,000mm Length, 4 -wire, Cylindrical, 30 mm x 40.6 mm dimentions, Embedded, Plastic, Polybutylene (PBT), 1 Piece(s) LEDs, Gray Silver color, IP 67 degree of protection. Capture the Best Deal with a Quote for your requirement of Leuze 40.6 Length Cylindrical Switch. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
