Many procurement teams check HTU208-100-NT-M8 against Sick Diffuse Sensor, Leuze Ls5B Xx 200 M12 and Leuze Proximity Sensor before signing purchase orders, verifying quality, compliance, and after-sales support availability.
Leuze HTU208-100/NT-M8 Ultrasonic Sensor
The Leuze HTU208-100/NT-M8 Ultrasonic Sensor offers a Cylindrical design, Transistor, NPN output, Connector , 4 -pin. Manufactured by Leuze under the Leuze Ultrasonic Sensor category, this model belongs to the 412B Series.
| Brand | Leuze |
| Product Type | Ultrasonic Sensor |
| Product | HTU208-100/NT-M8 |
Leuze HTU208-100/NT-M8 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Design | Cylindrical |
| Thread Size | M12 x 1 mm |
| Dimension | 8 mm x 70 mm |
| Operating range | 0.02 ... 0.1 m |
| Operating principle | Diffuse reflection principle with background suppression |
| Ultrasonic frequency | 484 kHz |
| Opening angle | 12 Β° |
| Adjustment range | 20 ... 100 mm |
| Resolution | 0.1 mm |
| Supply voltage UB | 18 ... 30 V, DC |
| Number of Connections | 1 Piece(s) |
| Switching voltage | high: β₯9V low: β€ 2 V |
| Switching output 1 | Transistor, NPN |
| Switching frequency | 20 Hz |
| Interface Type | - |
| Response time | 25 ms |
| Connection 1 Function | Signal OUT Teach input Voltage supply |
| Type of connection | Connector |
| No. of Pin | 4 -pin |
| Housing material | Metal |
| Ambient temperature, operation | 25 ... 70 Β°C |
| Ambient temperature, storage | -25 ... 70 Β°C |
| Degree of protection | IP 67 |
Get A Quote for Leuze Cylindrical Ultrasonic Sensors HTU208-100/NT-M8 50149528 at the best price. Here are the brief Technical Specifications of HTU208-100/NT-M8 8 mm x 70 mm Dimensions 0.02 ... 0.1 m Operating Range, 484 kHz Ultrasonic Frequency, 12 Β° Opening Angle, Transistor, NPN Switching Output, Connector, M12 x 1 mm Thread size, 4 -pin, Metal Housing material, IP 67 degree of protection. It's Time to get a Quote for your requirement of Leuze Cylindrical Ultrasonic Sensors. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
