Leuze HTU208-100/2T-M8 Ultrasonic Sensor
Leuze HTU208-100/2T-M8 Ultrasonic Sensor provides 0.02β0.1 m operating range, 484 kHz ultrasonic frequency, and 0.1 mm resolution. This Leuze Ultrasonic Sensor belongs to the 412B Series and features PNP transistor output, 20 Hz switching frequency, 18β30 V DC supply, 12Β° opening angle, 25 ms response time, 4-pin M8 connector, metal housing, and IP67 protection.
| Brand | Leuze |
| Product Type | Ultrasonic Sensor |
| Product | HTU208-100/2T-M8 |
Leuze HTU208-100/2T-M8 Ultrasonic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Design | Cylindrical |
| Thread Size | M12 x 1 mm |
| Dimension | 8 mm x 70 mm |
| Operating range | 0.02 ... 0.1 m |
| Operating principle | Diffuse reflection principle with background suppression |
| Ultrasonic frequency | 484 kHz |
| Opening angle | 12 Β° |
| Adjustment range | 20 ... 100 mm |
| Resolution | 0.1 mm |
| Supply voltage UB | 18 ... 30 V, DC |
| Number of Connections | 1 Piece(s) |
| Switching voltage | high: β₯9V low: β€ 2 V |
| Switching output 1 | Transistor, PNP |
| Switching frequency | 20 Hz |
| Interface Type | - |
| Response time | 25 ms |
| Connection 1 Function | Signal OUT Teach input Voltage supply |
| Type of connection | Connector |
| No. of Pin | 4 -pin |
| Housing material | Metal |
| Ambient temperature, operation | 25 ... 70 Β°C |
| Ambient temperature, storage | -25 ... 70 Β°C |
| Degree of protection | IP 67 |
The HTU208-100/2T-M8 Leuze M8 Connector 4 pin Ultrasonic Sensors model is a short-range sensing device within the 412B Series for precision automation. The HTU208-100/2T-M8 operates across a 0.02β0.1 m operating range using 484 kHz ultrasonic frequency and delivers 0.1 mm resolution with a 20 Hz switching frequency. As a Leuze Ultrasonic Sensor, it supports stable detection in compact industrial automation systems.
In conveyors, packaging units, assembly lines, and small component handling systems, the HTU208-100/2T-M8 ensures reliable object detection independent of surface color or reflectivity. The 12Β° opening angle enables focused sensing, while the PNP transistor output simplifies PLC integration. Its metal housing and IP67 rating support operation in demanding industrial environments.
The HTU208-100/2T-M8 from Leuze reinforces the structured architecture of Leuze ultrasonic sensors in the 412B Series. With defined adjustment range, cylindrical housing, and M8 connector-based wiring, it enables accurate short-distance measurement in Indian industrial automation applications.
