Leuze HT25C.S/4P Photoelectric Sensor
The HT25C.S/4P is a Photoelectric Sensor with 0–0.5 m sensing distance, PNP outputs, and red LED light source. The Leuze HT25C.S/4P belongs to the Leuze Photoelectric Sensor category and the HT series, operating on the diffuse reflection principle with background suppression, 10–30 V DC supply, 1,500 Hz switching frequency, 0.33 ms response time, 2,000 mm PUR cable, and IP66/IP67 protection.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | HT25C.S/4P |
Leuze HT25C.S/4P Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Diffuse reflection principle with background suppression |
| Special version | Small light spot (S) |
| Sensing Distance | 0 ... 0.5 m |
| Beam path | - |
| Light source | LED, Red |
| Wavelength | 640 nm |
| Type of light spot geometry | - |
| Supply voltage UB | 10 ... 30 V, DC, Incl. residual ripple |
| Switching Output 1 | Transistor, PNP |
| Switching principle | Light switching |
| Switching Output 2 | Transistor, PNP |
| Switching principle | Dark switching |
| Switching frequency | 1,500 Hz |
| Response time | 0.33 ms |
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PUR |
| Cable color | Black |
| Number of conductors | 4 -wire |
| Wire cross section | 0.2 mm² |
| Dimension (W x H x L) | 15 mm x 42.7 mm x 30 mm |
| Housing material | Plastic |
| Lens cover material | Plastic |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature, operation | -40 ... 60 °C |
| Ambient temperature, storage | -40 ... 70 °C |
| Degree of protection | IP 66/IP 67 |
The HT25C.S/4P is defined as Leuze< 10% up to 300 mm Black-white error diffuse sensor within the HT series of industrial Photoelectric Sensors. This HT25C.S/4P operates with 0–0.5 m sensing distance, 10–30 V DC supply, 1,500 Hz switching frequency, and IP66/IP67 protection. As part of the HT family, it uses diffuse reflection with background suppression and a small light spot configuration for stable short-range detection.
In packaging lines, conveyor systems, and assembly automation, the HT25C.S/4P supports reliable object detection at close distances. The red LED light source at 640 nm ensures consistent switching, while dual PNP outputs allow light and dark switching integration with PLC systems. The 4-wire, 2,000 mm cable simplifies panel wiring and control cabinet installation.
The Leuze HT25C.S/4P Photoelectric Sensor is structured for continuous industrial automation use. The HT25C.S/4P combines defined sensing range, 0.33 ms response time, and compact cubic housing to maintain stable signal output in temperature conditions from -40 to 60 °C. As a Leuze HT series model, it aligns with standardized electrical and optical specifications required in manufacturing environments.
