Leuze HRTR 318K/66-120 Photoelectric Sensor
The Leuze HRTR 318K/66-120 Photoelectric Sensor (Part No: ) offers a Cubic design, 0.001 ... 0.12 m sensing distance, Transistor, Push-pull output, PVC Cable , 4 -wire. Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the HT Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | HRTR 318K/66-120 |
Leuze HRTR 318K/66-120 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Design | Cubic |
| Operating principle | Diffuse reflection principle with background suppression |
| Special version | - |
| Sensing Distance | 0.001 ... 0.12 m |
| Beam path | Focused |
| Light source | LED, Red |
| Wavelength | 625 nm |
| Type of light spot geometry | Rectangular |
| Supply voltage UB | 10 ... 30 V, DC |
| Switching Output 1 | Transistor, Push-pull |
| Switching principle | Light switching (PNP)/dark switching (NPN) |
| Switching Output 2 | Transistor, Push-pull |
| Switching principle | Dark switching (PNP)/light switching (NPN) |
| Switching frequency | 1,000 Hz |
| Response time | 0.5 ms |
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Cable color | Black |
| Number of conductors | 4 -wire |
| Wire cross section | 0.2 mmΒ² |
| Dimension (W x H x L) | 18 mm x 50 mm |
| Housing material | Plastic |
| Lens cover material | Plastic |
| Housing color | Black Red |
| Type of display | LED |
| Ambient temperature, operation | -25 ... 65 Β°C |
| Ambient temperature, storage | -40 ... 70 Β°C |
| Degree of protection | IP 67 |
Send Your Inquiry for Leuze 270Β° potentiometer Operational controls diffuse sensor HRTR 318K/66-120 part no: 50106089 at affordable rates. Core System Specifications of HRTR 318K/66-120, 50106089 are Cubic, Design Diffuse reflection principle with background suppression, 18 mm x 50 mm Dimension, LED, Red Light source, Transistor, Push-pull Switching Outputs 1, Light switching (PNP)/dark switching (NPN) Switching principle, 10 ... 30 V, DC Supply voltage UB, 0.001 ... 0.12 m Sensing Distance, Cable Type of connection, Plastic Housing material, IP 67 degree of protection. Initiate Your Journey with a Quote for your requirement of Leuze 270Β° potentiometer Operational controls diffuse sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
