Leuze ELC110R17-1200 Safety Light Curtain
| Brand | Leuze |
| Product Type | Safety Light Curtain |
| Model Number | ELC110R17-1200 |
Leuze ELC110R17-1200 Safety Light Curtain β Technical Specifications
| Specification | Value |
|---|---|
| Series | ELC100 |
| Device type | Receiver |
| Contains | 2x sliding block |
| Application | Finger protection |
| Functions | Automatic start/restart |
| Resolution | 17 mm |
| Protective field height | 1,200 mm |
| Synchronization | Optical between transmitter and receiver |
| Protective circuit | Overvoltage protection, Short circuit protected |
| Supply voltage UB | 24 V, DC, -20 ... 20 % |
| Current consumption, max. | 100 mA |
| Number of safety-related switching outputs (OSSDs) | 2 Piece(s) |
| Safety related switching output Type | Safety-related switching output OSSD |
| Switching voltage high, min. | 18 V |
| Switching voltage low, max. | 2.5 V |
| Switching voltage, typ. | 22.5 V |
| Voltage type | DC |
| Current load, max. | 50 mA |
| Load inductivity | 500,000 Β΅H |
| Load capacity | 0.03 Β΅F |
| Residual current, max. | 0.5 mA |
| Voltage drop | 1.5 V |
| O/P 1: Switching Principle | 24 V switching |
| O/P 1: Switching Output | Transistor, PNP |
| O/P 2: Switching Principle | 24 V switching |
| O/P 2: Switching Output | Transistor, PNP |
| Response time | 17.3 ms |
| Restart delay time | 100 ms |
| Number of connections | 1 Piece(s) |
| Function | Machine interface |
| Type of connection | PUR Cable 300 mm with M12 connector 4 -pin |
| Type | Male |
| Dimension (W x H x L) | 34.7 mm x 1,215 mm x 39.3 mm |
| Housing material | Metal: Aluminum |
| Lens cover material | Plastic / PMMA |
| Material of end caps | Diecast zinc |
| Housing color | Yellow, RAL 1021 |
| Type of fastening | Groove mounting, Mounting brackets |
| Type of display | LED |
| Number of LEDs | 6 Piece(s) |
| Degree of protection | IP 65 |
| Protection class | III |
| Ambient temperature, operation | 0 ... 50 Β°C |
| Ambient temperature, storage | -30 ... 70 Β°C |
| Relative humidity (non-condensing) | 0 ... 95 % |
| Net weight | 1,730 g |
The ELC110R17-1200 from Leuze delivers advanced safety performance with a 17 mm resolution and an extended protective field height of 1,200 mm, making it ideal for finger protection in vertically installed guarding systems. Operating at 24 V DC with a tolerance of Β±20%, this safety light curtain receiver draws a maximum of 100 mA current, ensuring stable performance even in demanding factory environments.
It features two safety-related OSSD outputs using PNP transistor switching with a typical switching voltage of 22.5 V. The unit provides a fast response time of 17.3 ms and includes a restart delay of 100 ms to support safe system reactivation. Its PUR cable (300 mm) and M12 4-pin male connector make integration simple, while the LED status display with 6 indicators helps technicians monitor real-time status during commissioning or maintenance. With a robust aluminum housing, diecast zinc end caps, PMMA lens cover, and an IP65 protection rating, the ELC110R17-1200 is built for durability in environments exposed to dust, vibration, and moderate humidity. Measuring 34.7 mm x 1215 mm x 39.3 mm and weighing 1,730 g, it supports both groove mounting and mounting brackets for easy installation in modern safety setups.
The Leuze ELC110R17-1200 Safety Light Curtain is best suited for industrial applications where finger-level safety is required across larger machine openings. It is commonly used in automated press machines, robotic pick-and-place systems, tray sealing equipment, and vertical packaging machines where operator access is frequent and fast movement poses risk.
Thanks to its slim profile and long detection range, this model can be installed in narrow machine frames without affecting workflow. Maintenance staff benefit from the clear LED status indicators that speed up diagnostics, and engineers appreciate the plug-and-play setup enabled by the M12 connector. By reliably detecting finger-level intrusions, the ELC110R17-1200 ensures that machines stop instantly during unsafe access, preventing injury and ensuring compliance with safety standards like ISO 13849. It's a dependable solution trusted by manufacturing plants in industries like automotive, electronics, food & beverage, and packaging.
