Sendix 5020 - Kuebler Absolute Encoder
The Sendix 5020 from Kuebler is a high-speed, industrial-grade encoder engineered for precision motion control in rugged environments.
| Brand | Kuebler |
| Product Type | Rotary Encoders |
| Model Number | Sendix 5020 |
Kuebler Absolute Encoder Sendix 5020 Technical Specifications
| Specification | Value |
|---|---|
| Dimension | Ø 50 mm |
| Shaft type | 6 mm hollow shaft, through8 mm hollow shaft, through10 mm hollow shaft, through12 mm hollow shaft, through14 mm hollow shaft, through15 mm hollow shaft, through1/4 " hollow shaft, through3/8 " hollow shaft, through1/2 " hollow shaft, through5/8 " hollow shaft, through |
| Flange type | Spring element, longStator couplingTorque brackets longØ 50.80 mmØ 57.20 mmØ 63.00 mmØ 65.00 mm |
| Working temperature | -40 °C ... +85 °C |
| Protection level | IP65IP66IP67 |
| Connection types | Axial cableRadial cableTangential cableM23 connector radialM12 connector radialMIL connector |
| Max. rotational speed | 12.000 min-1 |
| Weight | 400 g |
| Scanning | optical |
| Resolution max. | 5.000 ppr incremental |
| Power supply | 5 V DC5...30 V DC10...30 V DC |
| Interfaces | GegentaktTTL / RS422Open Collector |
| on request | EX protection zone 2/22Further impulse counters/resolutionsSalt spray test |
The Kuebler Sendix 5020 is a compact yet powerful optical rotary encoder offering up to 5000 pulses per revolution for precise incremental feedback. Designed with a robust through hollow shaft architecture, it supports multiple shaft sizes ranging from 6 mm to 5/8", including 1/4", 3/8", and 1/2" options, making it ideal for direct shaft integration in diverse industrial machinery.
Its flexible flange configurations — such as spring element, stator coupling, and torque brackets — combined with various flange diameters including Ø 50.80 mm, Ø 63 mm, and more, ensure easy adaptability across machine platforms. The encoder handles high-speed applications with a maximum rotational speed of 12,000 min⁻¹ and operates reliably across temperature extremes from -40°C to +85°C. With ingress protection ratings up to IP67, the Sendix 5020 can withstand dust, humidity, and water jets in demanding industrial conditions.
It features multiple interface standards — TTL / RS422, Gegentakt, and Open Collector — and connection types including radial/axial/tangential cables, M12, M23, and MIL connectors. Its compatibility with 5 V DC to 30 V DC power supplies adds electrical flexibility, while optional variants for EX protection zone 2/22 and salt spray testing make it suitable for hazardous and corrosive environments. Weighing just 400 g, the encoder delivers exceptional performance in a lightweight housing.
The Sendix 5020 Encoder by Kuebler is tailored for high-precision, high-speed applications across automation and control systems. Its through hollow shaft design makes it a top choice in elevators, wind turbines, and conveyor systems, where continuous shaft rotation and alignment are crucial.
In the textile, packaging, and printing industries, the encoder’s high pulse resolution enables accurate feedback for synchronized motor control, improving throughput and minimizing material waste. Its robust construction, high ingress protection, and EX zone compliance also make it ideal for petrochemical plants, offshore rigs, and food-grade machinery requiring corrosion resistance and operational safety.
Whether used in retrofits or next-generation automation builds, the Kuebler Sendix 5020 Encoder offers consistent, high-speed incremental feedback that meets the real-world demands of modern industrial motion control.
