Koino CPX-D18-08E1N - Capacitive Proximity Sensors
Technical Specifications of Koino Capacitive Proximity Sensors CPX-D18-08E1N:
| Sensing Distance | 8.0mm |
| Connection Method | Pre-wired (2M) |
| Operation Mode | NPN NO |
Koino CPX-D18-08E1N Capacitive Proximity Sensors Technical Specifications
| Specification | Value |
|---|---|
| Sensor Type | DC 3-wire Capacitive Proximity Sensors |
| Sensing Distance | 8.0mm |
| Set Distance | 0~5.6mm |
| Connection Method | Pre-wired (2M) |
| Operation Mode | NPN NO |
| Shielding | Unshielded |
| Response Frequency | 100Hz |
| Power Supply Voltage | 10~30VDC |
| Rated Operating Voltage | 12~24VDC |
| Detectable Object | conductor/dielectric substance |
| Differential Travel | max. ±20% of sensing distance |
| Standard sensing object | Iron 50X50X1mm |
| Control Output (Load Current) | max. 200mA |
| Ambient Temperature (Operating) | -25℃ ~+70℃ |
| Ambient Temperature (Storage) | -30° C~+80° C |
| Ambient Humidity | 35~95%RH |
| Insulation Resistance | Minimum 50MΩ (500VDC) |
| Dielectric Strength | 1,500VAC 50/60Hz for 1min. |
| Vibration Resistance | 10~55Hz double amplitude 1.5mm (at X, Y and Z axis) for 2hrs |
| Shock Resistance | 50G |
| Degree of Protection | IP67 |
| Body Material | Nylon glass |
| Sensing Surface Material | Nylon glass |
