Itherm Px-413: Temperature Controller
Technical Specifications of Itherm Temperature Controller Px-413:
| Sampling Rate | 250msec |
| Output Relay | 5A @ 250 VAC/ 30VDC |
| Output SSR Drive | 41 VDC @ 30mA |
| Supply Voltage | 90 - 270 VAC/ DC
(24 VDC Available on Request) |
Itherm Px-413 Temperature Controller Technical Specifications
| Specification | Value |
|---|
| Height & Colour | 0.56'' White |
| No. of Digits | 3 Digits Single Row |
| LED Indication | Output Status |
| Sensor Input | T/C : J, KRTD : Pt-100 |
| Resolution | T/C: 1°C & Pt-100: 1°C |
| Sampling Rate | 250msec |
| Accuracy | 0.3% FS |
| Output Relay | 5A @ 250 VAC/ 30VDC |
| Output SSR Drive | 41 VDC @ 30mA |
| Supply Voltage | 90 - 270 VAC/ DC
(24 VDC Available on Request) |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20° to 75°C |
| Humidity | 95% RH (Non-condensing) |
| Dimensions in mm (H x W x D) | 48 x 48 x 70 |
