Procurement teams shortlist PI-77 with Itherm Pi 88, Itherm Process Indicator and Itherm Pid Temperature Controller Ai, aligning budget approvals, warranty terms, and multisite availability for smoother rollout across plants.
Itherm PI-77: Process Indicator
Technical Specifications of Itherm Process Indicator PI-77:
| Supply Voltage | 90 - 270 VAC/ DC(24 VDC Available on Request) |
| Sampling Rate | 250msec |
| Resolution | 1 / 0.1 / 0.01 / 0.001 |
| Analog Input | 0-1 VDC, 0-3.3 VDC, 0-5 VDC, 0-10VDC, 0-20 mA, 4-20 mA |
Itherm PI-77 Process Indicator Technical Specifications
| Specification | Value |
|---|---|
| Height & Color | 0.36'' White |
| No. of Digits | 4 Digits Single Row |
| Analog Input | 0-1 VDC, 0-3.3 VDC, 0-5 VDC, 0-10VDC, 0-20 mA, 4-20 mA |
| Resolution | 1 / 0.1 / 0.01 / 0.001 |
| Sampling Rate | 250msec |
| Accuracy | 0.3% FS |
| Supply Voltage | 90 - 270 VAC/ DC(24 VDC Available on Request) |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20° to 75°C |
| Humidity | 95% RH (Non-condensing) |
| Dimensions in mm (H x W x D) | 72 x 72 x 65 |
