Itherm AI-7683: Temperature Controller
Technical Specifications of Itherm Temperature Controller AI-7683:
| Sampling Rate | 250msec |
| Output Relay | 5A @ 250 VAC/ 30VDC |
| Output SSR Drive | 25 VDC @ 30mA |
| Supply Voltage | 90 - 270 VAC/ DC (24 VDC Available on Request) |
Itherm AI-7683 Temperature Controller Technical Specifications
| Specification | Value |
|---|---|
| Height & Colour | 0.36'' White & 0.36'' Pure Green |
| No. of Digits | 4 Digits Dual Row |
| LED Indication | Output Status & Soak Time |
| Sensor Input | T/C : J, K, R, S, N, T, BRTD : Pt-100 |
| Resolution | T/C : 1°C & Pt-100 : 1°C / 0.1°C |
| Sampling Rate | 250msec |
| Accuracy | 0.3% FS |
| Output Relay | 5A @ 250 VAC/ 30VDC |
| Output SSR Drive | 25 VDC @ 30mA |
| Alarm | Low/ High/ BandLow Deviation/ High Deviation |
| Soak Timer | Heater off / Alarm / Both |
| Supply Voltage | 90 - 270 VAC/ DC (24 VDC Available on Request) |
| Operating Temperature | 0-50°C |
| Storage Temperature | -20° to 75°C |
| Humidity | 95% RH (Non-condensing) |
| Dimensions in mm (H x W x D) | 96 x 48 x 53 |
