FC6A-D16P4CEE: Idec Micro Smart PLC
Technical Specifications of Idec Micro Smart PLC FC6A-D16P4CEE:
| Analog Input Type | 0-10 VDC |
| Program Capacity | 800K Bytes |
| Digital Output Type | Transistor Source |
Idec Micro Smart PLC FC6A-D16P4CEE Technical Specifications
| Specification | Value |
|---|---|
| Analog Input Type | 0-10 VDC |
| Battery | BR2032 |
| High-speed Counter | 100 Khz |
| iOS and Android App | WindEDIT Lite |
| Number of Embedded Output | 8 |
| Program Capacity | 800K Bytes |
| Programming Language | Ladder, Script |
| Communication Protocol | Modbus RTU BACnet/IP EtherNet/IP Modbus TCP MQTT |
| IP Rating | IP20 |
| Data register | 200000 |
| Internal relay | 15400 |
| Maximum number of expansion modules | 63 |
| Maximum Analog I/O Points | 511 |
| Maximum Digital I/O Points | 2044 |
| Timer | 2000 |
| Embedded Analog IO | 1 |
| Embedded Digital IO | 16 |
| Number of Embedded Input | 8 |
| SD Memory Slot | TRUE |
| Digital Output Type | Transistor Source |
| Number of Ethernet Port | 2 |
| USB Port | USB Mini-B |
| Operating Temperature | -25 to 65 deg. C |
| Operating voltage | 24VDC |
| Terminal Shape | Product Type |
