During technical comparisons, FC6A-C16R4AE appears alongside Idec Fc6A C16R1Ce, Idec Fc6A D32K3Cee and Idec Fc6A C16R1Ae so engineers assess signal types, ingress protection, and ambient tolerances accurately.
FC6A-C16R4AE: Idec Micro Smart PLC
Technical Specifications of Idec Micro Smart PLC FC6A-C16R4AE:
| Analog Input Type | 0-10 VDC |
| Program Capacity | 384K Bytes |
| Digital Output Type | Relay |
Idec Micro Smart PLC FC6A-C16R4AE Technical Specifications
| Specification | Value |
|---|---|
| Analog Input Type | 0-10 VDC |
| Battery | BR2032 |
| High-speed Counter | 100 Khz |
| iOS and Android App | WindEDIT Lite |
| Maximum Expandable Serial Ports | 8 |
| Number of Embedded Output | 7 |
| Program Capacity | 384K Bytes |
| Programming Language | Ladder, Script |
| Communication Protocol | Modbus RTU Modbus TCP |
| IP Rating | IP20 |
| Data register | 56000 |
| Internal relay | 12400 |
| Maximum number of expansion modules | 12 |
| Maximum Analog I/O Points | 101 |
| Maximum Digital I/O Points | 404 |
| Timer | 1024 |
| Embedded Analog IO | 1 |
| Embedded Digital IO | 16 |
| Number of Embedded Input | 9 |
| SD Memory Slot | TRUE |
| Digital Output Type | Relay |
| Embedded Serial Port | 1 |
| Number of Ethernet Port | 1 |
| USB Port | USB Mini-B |
| Operating Temperature | -25 to 65 deg. C |
| Operating voltage | 100-240VAC |
| Terminal Shape | Product Type |
