GIC PS150W24V Power Supplies
The GIC PS150W24V Panel Mount Power Supplies (SMPS) offers 150W max output Power, -30°C to +70°C deg operating Temperature, 159x97x37.1mm dimensions (LxWxH), Panel / DIN Rail Mount mounting type. Manufactured by GIC under the GIC Panel Mount Power Supplies category, this model belongs to the GIC PS Series.
| Brand | GIC |
| Product Type | Power Supplies |
| Model Number | PS150W24V |
GIC PS150W24V Power Supplies – Technical Specifications
| Specification | Value |
|---|---|
| Supply Voltage | 85V to 132V AC / 170V to 264V AC – Select able through Switch, 240V to 370V DC (When Switch is on 230V AC) |
| Frequency Range | 47 to 63Hz |
| Efficiency | 89.00% |
| AC Current | 3A @ 115V Ac ; 1.7A @ 230V AC |
| Inrush Current | Cold start 60A @ 230V AC |
| No Load Power Consumption | <0.5W @230V AC |
| Output DC voltage | 24V |
| Output DC voltage adjustment range | 21V to 28V DC |
| Output Current | 6.25A @24VDC |
| Output Power | 150W max |
| Ripple & Noise | 120mV Ripple max |
| Startup Time | 500msec at full load |
| Rise Time | 30msec at full load |
| Hold up time | 168% of rated output (Max.30msec at full load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 115 & 230Vac input, 10-100% load (Slew Rate: 2.5A/μS, 50% duty cycle @ 5Hz & 10KHz) |
| Start-up with Capacitive Loads | 8,000µF Max |
| Over Voltage | 28.8V to 33.6V Shut down O/P voltage , re-power ON to recover |
| Over load/ Over current | 110 to 140% rated output power Hiccup mode, recovers automatically after fault recovery |
| Over temperature | Shut down output voltage, re-power ON to recover |
| Short circuit | Hiccup mode, recovers automatically after fault recovery |
| Protection against shock | Class 1 with Protection Earth connection |
| Over temperature protection | Low – 0°C to High - 50°C ambient temp. range 70°C with de-rating of 2.5%/°c above 50°c. Forced air cool (Refer de-rating curve) |
| Pot | For output voltage setting |
| LED Indication | Green LED : ON : DC O/P OK |
| Operating Temperature | -30°C to +70°C deg |
| Storage Temperature / Humidity | -40°C to +85°C / 10 - 90% RH non-condensing |
| Operating Relative humidity | 20 - 90% RH non-condensing |
| Operating Altitude | Up to 2000 meters |
| Over voltage Category | III |
| Pollution degree | 3 |
| Vibration Test | Operating & Non-Operating as per : IEC 60068-2-6 |
| Shock Test | Operating & Non-Operating as per : IEC 60068-2-27 |
| Case chassis | Aluminium |
| Dimensions (LxWxH) | 159x97x37.1mm |
| Unit weight | Approx. 400g |
| Cooling system | Convection |
| Terminals | M3.5 x 7 Pins (Rated 300V/20A), 7 terminals : L , N , E , -V, -V, +V, +V Terminals should be Front & Top side wire insert-able |
| Terminal Type | Upward facing terminal |
| Wire | AWG 22-12 |
| Mounting type | Panel / DIN Rail Mount |
| MTBF | > 700,000 hrs as per IEC 62380 |
